SDR-480_10

480W Single Output Industrial DIN RAIL with PFC Function Features : SDR-480 series High efficiency 94% and low power dissipation 150% peak load capability Built-in active PFC function, PF>0.94 Protections: Short circuit / Overload / Over voltage / Over temperature Cooling by free air convection Built-in constant current limiting circuit Can be installed on DIN rail TS-35/7.5 or 15 UL 508(industrial control equipment)approved EN61000-6-2(EN50082-2) industrial immunity level Built-in DC OK relay contact 100% full load burn-in test 150% peak load capability 3 years warranty SE PQ M IF 47 GL SPECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER PEAK CURRENT PEAK POWER Note.6 OUTPUT VOLTAGE ADJ. RANGE LINE REGULATION LOAD REGULATION SETUP, RISE TIME HOLD UP TIME (Typ.) VOLTAGE RANGE FREQUENCY RANGE POWER FACTOR (Typ.) INPUT EFFICIENCY (Typ.) AC CURRENT (Typ.) INRUSH CURRENT (Typ.) LEAKAGE CURRENT OVERLOAD PROTECTION OVER VOLTAGE OVER TEMPERATURE SDR-480-24 24V 20A 0 ~ 20A 480W 30A 720W (3sec.) 120mVp-p 48 ~ 55V 1.0% 0.5% 1.0% 3000ms, 150ms/115VAC at full load SDR-480-48 48V 10A 0 ~ 10A 480W 15A RIPPLE & NOISE (max.) Note.2 100mVp-p 24 ~ 28V VOLTAGE TOLERANCE Note.3 1.2% 0.5% 1.0% 1500ms, 150ms/230VAC 14ms/230VAC at full load Note.7 90 ~ 264VAC 127 ~ 370VDC 0.99/115VAC at full load 2.5A/230VAC 80A/230VAC 47 ~ 63Hz 0.94/230VAC 94% 5A/115VAC 40A/115VAC 150% rated power, constant current limiting with auto-recovery within 2 seconds and may cause to shut down if over 2 seconds 56 ~ 65V 29 ~ 33V Protection type : Shut down o/p voltage with auto-recovery or re-power on to recovery 105 5 (TSW : detect on heatsink of power switch) Protection type : Shut down o/p voltage, recovers automatically after temperature goes down FUNCTION DC OK REALY CONTACT RATINGS (max.) 60Vdc/0.3A, 30Vdc/1A, 30Vac/0.5A resistive load WORKING TEMP. Note.5 -25 ~ +70 (Refer to output load derating curve) 20 ~ 95% RH non-condensing WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS WITHSTAND VOLTAGE -40 ~ +85 , 10 ~ 95% RH 0.03%/ (0 ~ 50 Component:10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6 UL508, TUV EN60950-1 approved I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC O/P-DC OK:0.5KVAC / 70% RH I/P-O/P, I/P-FG, O/P-FG:>100M Ohms / 500VDC / 25 SAFETY & ISOLATION RESISTANCE EMI CONDUCTION & RADIATION Compliance to EN55022 (CISPR22) Class B EMC (Note 4) Compliance to EN61000-3-2,-3 HARMONIC CURRENT EMS IMMUNITY MTBF OTHERS NOTE Compliance to EN61000-4-2,3,4,5,6,8,11, ENV50204, EN55024, EN61000-6-2 (EN50082-2), EN61204-3, heavy industry level, criteria A , SEMI F47, GL approved 112.9Khrs min. MIL-HDBK-217F (25 85.5*125.2*128.5mm (W*H*D) 1.6Kg; 8pcs/13.8Kg/0.9CUFT ) DIMENSION PACKING 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation. 4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. 5. Installation clearances : 40mm on top, 20mm on the bottom, 5mm on the left and right side are recommended when loaded permanently with full power. In case the adjacent device is a heat source, 15mm clearance is recommended. 6. 3 seconds peak power max. and the average output power should not exceed the rate power. 7. Derating may be needed under low input voltage. Please check the derating curve for more details. File Name:SDR-480-SPEC 2010-12-07 480W Single Output Industrial DIN RAIL with PFC Function Mechanical Specification SDR-480 series Case No.984A Unit:mm 125.2 TB2 1 2 3 4 5 6 7 8 + 85.5 TB1 1 2 3 128.5 +V ADJ DC OK DC OK Terminal Pin No. Assignment (TB1) Pin No. 1 2 3 Assignment FG AC/N AC/L 35 Terminal Pin No. Assignment (TB2) ADMISSIBLE DIN-RAIL:TS35/7.5 OR TS35/15 Pin No. 1,2 3,4 5,6 7,8 Assignment DC OUTPUT +V DC OUTPUT -V Relay Contact NC Block Diagram DC OK I/P EMI FILTER & RECTIFIERS PFC CIRCUIT POWER SWITCHING RECTIFIERS & FILTER O.C.P. +V -V U.V.P. FG PFC CONTROL O.L.P. PWM & PFC CONTROL DETECTION CIRCUIT O.V.P. DC OK Relay Contact Contact Close Contact Open PSU turns on / DC OK. PSU turns off / DC Fail. Contact Ratings (max.) 30V/1A resistive load. F ile Name:SDR-480-SPEC 2010-12-07 480W Single Output Industrial DIN RAIL with PFC Function Peak Loading (1) 720W (2) 720W SDR-480 series 480W 50 sec. 3 sec. 240W 15 sec. 3 sec. Derating Curve Output derating VS input voltage 150 100 90 120 For 3 sec. (typ.) 80 70 100 LOAD (%) LOAD (%) 40 50 60 70 (VERTICAL) 80 Continuous 60 50 40 60 -25 0 10 20 30 90 100 110 135 155 230 264 AMBIENT TEMPERATURE ( ) INPUT VOLTAGE (V) 60Hz File Name:SDR-480-SPEC 2010-12-07
