PD-40-250

PD & PDB-40 Series 0 POWER DIVIDERS/COMBINERS 1 to 500 MHz / 4-Way / Uniform Phase & Ampli. Bal. / Low Insert. Loss / 50 & 75 Ohm Units / BNC PRINCIPAL SPECIFICATIONS Model Number PD-40-100 (75Ω Model) Frequency Frequency Isolation, Insertion Phase Amplitude VSWR Input Range, Performance, dB, Loss, dB, Balance Bal., dB, (In/Output) Power† MHz MHz Min. Typ. Max. Typ. Max. Typ. Max. Typ. Max. Typ. W, Max. 1 - 200 1 - 200 10 - 500 1 - 100 100 - 200 1 - 100 100 - 200 10 - 500 30 20 30 20 25 35 30 35 30 30 1.0 1.2 1.0 1.2 1.25 0.5 0.8 0.5 0.8 0.8 3° 4° 3° 4° 3° 1° 2° 1° 2° 2° 0.2 0.3 0.2 0.3 0.3 0.1 0.2 0.1 0.2 0.2 1.3:1 1.2:1 1.5:1 1.3:1 1.3:1 1.2:1 1.5:1 1.3:1 1.35:1 1.2:1 2 2 2W PDB-40-100 PD-40-250 †CW power input when used as power divider with 1.2:1 VSWRout) GENERAL SPECIFICATIONS General Notes: 1. The PD-40 and PDB-40 series of 4-way power dividers/combiners use lumped element circuits for broadband performance and high output port isolation. Coupling: Impedance: Internal Load Dissipation: Operating Temperature: -- 6 dB nom. 50 Ω nom. 250 mW max. -- 55° to +85°C Package Outline NOTES: 1. Tolerance on 3 place decimals ±.020(.51) except as noted. 2. Dimensions in inches over mm. 3. Weight, nominal: 2.5 oz. (100 g). 22Feb96 For further information contact MERRIMAC / 41 Fairfield Pl., West Caldwell, NJ, 07006 / 973-575-1300 / FAX 973-575-0531
