PDF-2A-50SQ

PDF-2A-50 SQ 0° DIVIDERS / COMBINERS REV: 002, 08/23/01 • SPACE QUALIFIED • 1 - 100 MHz • 2 WAY FLATPACK SERIES 05 TECHNICAL DESCRIPTION / APPLICATION The PDF-2A-50 SQ 2 way power divider/combiner covers a frequency range of 1 to 100 MHz using a special lumped element design to reduce the size while maintaining high performance. This device has been designed in accordance with Merrimac document CENG-0001, “Standard Design Requirements for Space Qualified Devices”. GENERAL SPECIFICATIONS MODEL NUMBER FREQUENCY RANGE MHz PDF-2A-50 SQ INPUT POWER MAX 1 - 100 COUPLING NOM. 1W 3.0 dB ISOLATION dB MIN. 30 TYP. 35 INSERTION LOSS dB MAX. 0.7 TYP. 0.5 AMPLITUDE BALANCE dB MAX. 0.15 TYP. 0.1 PHASE BALANCE MAX. 2° TYP. 1° VSWR INPUT/ OUTPUT MAX. 1.3:1 TYP. 1.2:1 IMPEDANCE NOM. 50 OHM INTERNAL POWER DISSIPATION MAX. 50 mW WEIGHT MAX. 2.8 g OPERATING TEMPERATURE -55° to +85 ° C PACKAGE OUTLINE Merrimac Industries, RF & Microwave Products Division / 41 Fairfield Place, West Caldwell, NJ 07006 Tel: 973.575.1300 / Fax: 973.575.0531 / Internet: www.Merrimacind.com
