PDM-20-1100

PDM-20 Series 0 POWER DIVIDERS / COMBINERS 50 kHz to 2 GHz / 2-Way / Uniform Phase & Ampli. Bal./ Low Insertion Loss / Lumped Element / SMA PRINCIPAL SPECIFICATIONS Model Number PDM-20-10 PDM-20-50 PDM-20-250 Freq. Range, MHz 0.05 - 20 1 - 100 10 - 500 Freq, Perform., MHz Isolation, Insertion Phase Amplitude dB, Loss, dB, Balance, Balance, dB, Min. Typ. Max. Typ. Max. Typ. Max. Typ. 30 30 30 30 25 23 15 33 35 32 32 30 27 20 0.5 0.5 0.5 0.6 1.0 1.0 1.5 0.3 0.3 0.4 0.5 0.7 0.3 0.8 1° 1° 2° 2° 2° 4° 6° 0.5° 0.5° 1° 1° 1° 2° 3° 0.2 0.2 0.2 0.2 0.2 0.3 0.3 0.1 0.1 0.1 0.1 0.1 0.1 0.1 VSWR Input In/Out Power* Max. Typ. Max. 1.3:1 1.3:1 1.3:1 1.3:1 1.3:1 1.4:1 2.0:1 1.2:1 1.2:1 1.2:1 1.2:1 1.2:1 1.2:1 1.5:1 2W 3W 3W 3W 1W 2W 2W 0.05 - 20 1 - 100 10 - 400 10 - 500 PDM-20-500 5 - 1000 5 - 1000 PDM-20-1100 200 - 2000 500 - 1500 200 - 2000 *CW input power when used as divider with 1.2:1 VSWRout. General Notes: 1. The PDM-20 series of connectorized two way In-Phase Power Dividers/Combiners covers 50 kHz to 2 GHz using lumped element design providing very broad bandwidths. GENERAL SPECIFICATIONS Impedance: 50 Ω nom. Internal Load Dissipation: PDM-20-1100: 125 mW max. All Others: 250 mW max. Weight, nominal: 1 oz. (28 g) Operating Temperature: -- 55° to +85°C Package Outline NOTES: 1. Tolerance on 3 place decimals ±.020(.51) except as noted. 2. Dimensions in inches over millimeters. 19Feb96 For further information contact MERRIMAC / 41 Fairfield Pl., West Caldwell, NJ, 07006 / 973-575-1300 / FAX 973-575-0531
