PDT-30-50

PDT-30-50 0 POWER DIVIDER/COMBINER 1 to 100 MHz / 3-way / Broadband / High Output Isolation / Low Insertion Loss/ TO-5 Package PRINCIPAL SPECIFICATIONS Model Number PDT-30-50 Frequency Frequency Range, Performance, MHz MHz 1 - 100 1 - 100 Isolation, Insertion dB, Loss, dB, Min. Typ. Max. Typ. 30 32 0.5 0.3 Phase Balance, Max. Typ. 2° 1° Amplitude VSWR Balance (In/Output) Max. Typ. Max. Typ. 0.2 0.1 1.3:1 1.15:1 Package Outline GENERAL SPECIFICATIONS Coupling: Impedance: Internal Power Dissip.: Average Power: Package Type: Weight, nominal: Operating Temperature: -- 4.8 dB nom. 50 Ω nom. 50 mW 1 Watt max. TO-5 0.1 oz. (2.8 g) -- 55° to +85°C General Notes: 1. The PDT-30-50 3-way Power Divider/Combiner covers a broad frequency range from 1 to 100 MHz using a special lumped element design to reduce the size to a minimum. 2. This design is isuitable for those applications where high performance and minimum size is essential. NOTES: 1. Tolerance on 3 place decimals ±.010(.25) except as noted. 2. Dimensions in inches over millimeters. 19Feb96 For further information contact MERRIMAC / 41 Fairfield Pl., West Caldwell, NJ, 07006 / 973-575-1300 / FAX 973-575-0531
