PDU-20-250

PDG & PDU-20-250 0 POWER DIVIDERS/ COMBINERS 5 to 500 MHz / 2-Way / Ultra Miniature / High Output Isolation / Low Insertion Loss / SMA PRINCIPAL SPECIFICATIONS Model Number PDU-20-250 Frequency Frequency Isolation, Insertion Phase Amplitude Range, Performance, dB, Loss, dB, Balance Balance, dB, MHz MHz Min. Typ. Max. Typ. Max. Typ. Max. Typ. 5 - 500 5 - 500 25 30 0.7 0.5 2° 1° 0.2 0.1 VSWR In/Output Max. Typ. 1.35:1 1.2:1 PDG-20-250 Outline GENERAL SPECIFICATIONS Coupling: Impedance: Internal Load Dissip.: CW Input Power: Weight, nominal: -- 3 dB nom. 50 Ω nom. 250 mW max. 1 Watt max 0.32 oz. (9 g) (When used as divider with 1.2:1 VSWRout) Operating Temperature: -- 55° to + 85°C PDU-20-250 Outline General Notes: 1. The PDG-20-250 and PDU-20250 2-way Power Dividers/Combiners cover a broad frequency range from 5 MHz to 500 MHz using a special high performance lumped element design to reduce overall size. 2. These units are suited for connectorized applications where an ultra-miniature package is essential. NOTES: 1. Tolerance on 3 place decimals ± .020(.51) except as noted. 2. Dimensions in inches over millimeters. 24May96 For further information contact MERRIMAC / 41 Fairfield Pl., West Caldwell, NJ, 07006 / 973-575-1300 / FAX 973-575-0531
