GLASS PASSIVATED RECTIFIER 8A05 THRU 8A10 FEATURES • • • • • • • • VOLTAGE RANGE CURRENT 50 to 1000 Volts 8.0 Ampere TO-220AC Glass passivated chip junction Low power loss, high efficiency Low Leakage High current capacity, high surge capacity High temperature soldering guaranteed 200℃/10 second,0.16”(4.06mm)lead length from case Also available in reverse polarity, add the “R” Suffix , i.e. 8A05R Also available in isolated package under part number 8AF05 MECHANICAL DATA • • • • • • Case: Transfer molded plastic Epoxy: UL94V-0 rate flame retardant Polarity: Marked on package Lead: Plated axial lead, solderable per MIL-STD-202E method 208C Mounting position: Any Weight: 0.064ounce, 1.81 gram Dimensions in inches and (millimeters) MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS Ratings at 25℃ ambient temperature unless otherwise specified Single Phase, half wave, 60Hz, resistive or inductive load For capacitive load derate current by 20% SYMBOLS 8A05 8A1 Maximum Repetitive Peak Reverse Voltage VRRM 50 100 Maximum RMS Voltage VRMS 35 70 Maximum DC Blocking Voltage VDC 50 100 • • • Maximum Average Forward Rectified Current TA Tc=100℃ Peak Forward Surge Current 8.3mS single half sine wave superimposed on rated load (JEDEC method) Maximum Instantaneous Forward Voltage at 8.0A Maximum DC Reverse Current at rated TA = 25℃ DC Blocking Voltage per element T = 125℃ A 8A2 200 140 200 8A4 400 280 400 8.0 175 1.1 1.0 200 55 2.5 (-55 to +150) (-55 to +150) 8A6 600 420 600 8A8 800 560 800 8A10 1000 700 1000 UNIT Volts Volts Volts Amps Amps Volts µA pF ℃/W ℃ ℃ I(AV) IFSM VF IR CJ RθJC TJ TSTG Typical Junction Capacitance ( Measured at 1.0MHz and applied reverse voltage of 4.0V) Typical Thermal Resistance (NOTE 1) Operating Temperature Range Storage Temperature Range Notes: 1. Unit mounted on heatsink E-mail: sales@cnmic.com Web Site: www.cnmic.com GLASS PASSIVATED RECTIFIER 8A05 THRU 8A10 VOLTAGE RANGE CURRENT 50 to 1000 Volts 8.0 Ampere RATING AND CHRACTERISTIC CURVES 8A05 THRU 8A10 FIG.1-TYPICAL FORWARD CURRENT DERATING CURVE AVERAGE FORWARD CURRENT, (A) 3.0 FIG.2-MAXIMUM NON-REPETITIVE PEAK FORWARD SURGE CURRENT PEAK FORWARD SURGE 200 CURRENT, (A) 8.3ms Single Half Sine-Wave (JEDEC Method) T= Tjmax 2.0 100 1.0 Single Phase Half Wave 60Hz Resistive or Inductive Load 0.375″(9.5mm) Lead Length 0 0 25 50 75 100 125 150 175 0 1 1 Cycle 2 4 6 8 10 20 40 60 100 AMBIENT TEMPERATURE, (° C) NUMBER OF CYCLES AT 60 Hz FIG.3-TYPICAL INSTANTANEOUS FORWARD CHARACTERISTICS 1000 FIG.4-TYPICAL REVERSE CHARACTERISTICS INSTANTANEOUS FORWARD CURRENT, 100 INSTANTANEOUS REVERSE CURRENT, (μA) 100 TJ=125° C 10 (A) 1.0 10 TJ =25° C Pulse Width=300us 1% Duty Cycle 0.1 0.4 0.8 1.2 1.6 1.0 TJ=25° C INSTANTANEOUS FORWARD VOLTAGE,(V) 0.1 0 20 40 60 80 100 120 140 FIG.5-TYPICAL JUNCTION CAPACITANCE PERCENT OF RATED PEAK 100 REVERSE VOLTAGE,(%) JUNCTION CAPACITANCE,(pF) 10 TJ =25° C f=1MHz Vsig=50mVp-p 1 0.1 1.0 10 100 REVERSE VOLTAGE,(V) E-mail: sales@cnmic.com Web Site: www.cnmic.com
