62000 GaAs LIGHT EMITTING DIODE “PILL PACK” (TYPE GS1140) Mii OPTOELECTRONIC PRODUCTS DIVISION Features: • • • • • Hermetically sealed High output, 940nm Small package PC board mountable Spectrally matched to the 61055 series detector Applications • • • • Incremental encoding Reflective sensors Position sensors Level sensors DESCRIPTION The 62000 is a P-N GaAs Infrared Light Emitting Diode in a lensed “pill” package designed to be mounted in a double-clad printed circuit board. It is spectrally and mechanically matched to companion phototransistors and photodarlingtons with it’s narrow beam angle lens and small size which make it ideal for use in optical encoders, card reader arrays, etc. Available binned to customer specifications and/or screened to MIL-PRF-19500. ABSOLUTE MAXIMUM RATINGS Storage Temperature..........................................................................................................................................-65°C to +150°C Operating Temperature ......................................................................................................................................-65°C to +125°C Reverse Voltage( at 25°C case temperature) ...................................................................................................................... 2Vdc Forward Current-Continuous .............................................................................................................................................100mA Soldering Temperature (3 Minutes) ................................................................................................................................... 240°C Package Dimensions Schematic Diagram 0.019 [0.48] 0.009 0.23] CERAMIC LENS R0.010 ±0.001 [0.25] 0.092 [2.34] 0.084 [2.13] Ø0.061 [1.55] Ø0.058 [1.47] ANODE 0.067 [1.70] 0.063 [1.60] CATHODE 0.010 [0.25] 0.005 [0.013] 0.088 [2.24] 0.082 [2.08] 0.115 [2.92] 0.102 [2.59] ALL DIMENSIONS ARE IN INCHES [MILLIMETERS] 0.24 [0.61] 0.016 [0.41] MICROPAC INDUSTRIES, INC. OPTOELECTRONIC PRODUCTS DIVISION • 725 E.Walnut St., Garland, TX 75040 • (972) 272-3571 • Fax (972) 487-6918 www.micropac.com E-MAIL: optosales@micropac.com 6 - 23 62000 ELECTRICAL CHARACTERISTICS TA = 25°C unless otherwise specified. GaAs LIGHT-EMITTING DIODE “PILLPACKAGE” PARAMETER Output Power 62000-X01 62000-X02 62000-X03 62000-X04 62000-XXX 62000-XXX 62000-XXX 62000-XXX 62000-XXX 62000-XXX SYMBOL PO MIN 0.25 0.40 1.0 1.5 TYP 0.3 0.65 1.2 1.6 MAX UNITS mW TEST CONDITIONS IF = 50mA NOTE Forward Voltage Reverse Breakdown Voltage Radiation Rise Time Peak Wavelength Beam Angle Forward Max Continuous Current VF BVR 2 0.7 940 20 1.6 V V µs nm degrees IF =50mA IB = 10µA tR λP IF =50mA 1 θ IF(MAX) 100 mA 25°C Case NOTES: 1. Low profile 40° lens also available. INSTANTANEOUS POWER OUTPUT versus FORWARD CURRENT P POWER OUTPUT INORMALIZED o 110 7 4 2 1 0.7 0.4 0.2 0.1 10 R ELATIV E IN TEN SITY TC =25°C NORMALIZED TO OUTPUT AT IF = 50 mA RADIATION PATTERN 1.0 0.8 0.6 0.4 0.2 0 20 400 40 70 100 200 IF FORWARD CURRENT [mA] 1000 40 20 0 20 40 AN G LE [DE G R EES ] POWER OUTPUT versus JUNCTION TEMPERATURE POWER OUTPUT [NORMALIZED] 3.0 2.0 P POWER OUTPUT [NORMALIZED] o 1.0 IF =50 mA T = 25° C A RELATIVE SPECTRAL OUTPUT 0.8 0.6 1 0.7 0.5 0.4 0.2 P o 0.3 -75 0 -50 -25 0 25 50 75 100 150 8800 9200 9600 10,000 TJ - JUNCTION TEMPERATURE - °C WAVELENGTH ( ) MICROPAC INDUSTRIES, INC. OPTOELECTRONIC PRODUCTS DIVISION • 725 E.Walnut St., Garland, TX 75040 • (972) 272-3571 • Fax (972) 487-6918 www.micropac.com E-MAIL: optosales@micropac.com 6 - 23 62000 PARAMETER Forward Current PART NUMBER 62000-001 62000-101 62000-002 62000-102 62000-003 62000-103 62000-004 62000-104 SYMBOL IF GaAs LIGHT-EMITTING DIODE “PILLPACKAGE” RECOMMENDED OPERATING CONDITIONS: MIN 50 MAX 100 UNITS mA PO Range +0.25 mW +0.25 mW +0.4 mW +0.4 mW +1 mW +1 mW +1.5 mW +1.5 mW SELECTION GUIDE PART DESCRIPTION GaAs LED in pill package, commercial version GaAsLED in pill package (-55° to +100°C) with 100% screening GaAs LED in pill package, commercial version GaAsLED in pill package (-55° to +100°C) with 100% screening GaAs LED in pill package, commercial version GaAsLED in pill package (-55° to +100°C) with 100% screening GaAs LED in pill package, commercial version GaAsLED in pill package (-55° to +100°C) with 100% screening MICROPAC INDUSTRIES, INC. OPTOELECTRONIC PRODUCTS DIVISION • 725 E.Walnut St., Garland, TX 75040 • (972) 272-3571 • Fax (972) 487-6918 www.micropac.com E-MAIL: optosales@micropac.com 6 - 23
