S16-4148_05

S16-4148, e3 8700 E. Thomas Road Scottsdale, AZ 85251 Tel: (480) 941-6300 Fax (480) 947-1503 and S16-4150, e3 Switching Diode Array FEATURES • • • • 8 Diode Array SOIC 16 pin Surface Mount Package UL 94V-0 Flammability Classification RoHS compliant by adding “e3” suffix (S16-4148e3 or S16-4150e3) MECHANICAL and PACKAGING • • • • • • • Molded SOIC 16 Pin Terminals: Tin-Lead or RoHS compliant annealed matte Tin Weight: 0.128 grams (approximate) Marking: Logo, device part number, date code Pin #1 defined by DOT on top of package Tape & Reel option: Standard per EIA-481-B 13 inch reel 2,500 pieces (add “TR” suffix to part number) Carrier tube 48 pcs per (STANDARD) CIRCUIT DIAGRAM MAXIMUM RATINGS • • • • • • Operating Temperatures: -55 C to +150 C 0 0 Storage Temperature: -55 C to +150 C Forward Surge Current: 2.0 Amps (8.3 ms) Working Peak Reverse Voltage VRWM: 75 V for S16-4148 and 50 V for S16-4150 Continuous forward current IF: 400 mA (each diode) Power dissipation (PD): 1500 mW (total package) 0 0 ELECTRICAL CHARACTERISTICS @ 250C Unless otherwise specified Part Number VBR @ IBR =100µA V MIN IR +25ºC µA MAX .025 .500 .1 V@Vr 20 75 50 IR 150ºC µA MAX 50 100 100 @VR 20 50 50 CAP @ 0V pF MAX pF 4.0 2.5 VF @ IF = 100 mA V MIN -----0.82 V MAX 1.20 0.92 trr MAX (nS) 5.0 4.0 VF @ IF = 200 mA V MIN -----0.87 V MAX -----1.00 S16-4148 S16-4150 Part Number S16-4148 S16-4150 A 90 75 VF @ IF = 1.0 mA V MIN -----0.54 V MAX -----0.62 VF @ IF = 10 mA V MIN -----0.66 V MAX 100 0.74 VF @ IF = 50 mA V MIN -----0.76 V MAX -----0.86 INCHES DIM A B C D F G MIN 0.385 0.150 0.053 0.011 0.016 0.050 BSC 0.006 0.004 0.189 0.228 0.010 0.010 0.206 0.244 MAX 0.398 0.158 0.069 0.021 0.050 MILLIMETERS MIN 9.09 3.81 1.35 0.28 0.41 1.27 BSC 0.15 0.10 4.80 5.79 0.25 0.20 5.23 6.19 MAX 10.10 4.01 1.75 0.53 1.27 B P G D C K J J L K L P F MSC0881.PDF ISO 9001 CERTIFIED REV G 7/20/2005
