319-10-101-30-041000

Series 319, 330, 399 SPRING-LOADED CONNECTORS 2,54 Grid Target Connectors for Spring-Loaded Assemblies Single Row Number of Pins X 2,54 2,54 2,54 2,54 1,78 DIA. 2,79 1,35 DIA. 4,19 4,29 7,37 • Series 319, 330 and 399 single row strips may be cut to any length. • Spring Target connectors present a large flat surface for making tangent connections to our standard 1,07 dia spring pin plungers. The target connectors provide an excellent gold plated conductive path back to the board mounted spring pin connector. • Target connectors use MM #1938, #1940, #1941, #1942 and #3024 pins. See page 185 for details. 0,51 DIA. Fig. 1 1,78 DIA. 2,79 1,35 DIA. 4,19 7,37 3,18 • Insulators are high temp. thermoplastic. Ordering Information Series 319...041 SMT w/ Alignment Pins 319-10-1_ _-30-041000 Specify # of pins 01-64 0,51 DIA. Fig. 2 1,83 DIA. 2,79 1,35 DIA. 4,19 Fig. 1 9,70 0,46 DIA. 5,51 Fig. 2 Series 319...001 Standard Solder Tails 319-10-1_ _-00-001000 Specify # of pins 01-64 Fig. 3 1,83 DIA. 2,79 1,35 DIA. 4,19 11,2 14,4 Fig. 3 Series 319...002 Long Solder Tails 319-10-1_ _-00-002000 Specify # of pins 01-64 0,86 DIA. 0,51 DIA. 3,20 Fig. 4 Series 319...005 Elevated Solder Tails 319-10-1_ _-00-005000 Specify # of pins 01-64 Fig. 4 1,83 DIA. 2,79 7,37 Fig. 5 Series 330...240 Solder Cups 330-10-1_ _-00-240000 Specify # of pins 01-64 1,35 DIA. 2,29 1,52 0,97 DIA. HOLE Fig. 5 4,19 2,79 Fig. 6 Series 399...008 Right Angle Solder Tails 399-10-1_ _-10-008000 Specify # of pins 01-64 2,54 4,47 5,74 0,46 DIA. For Electrical, Mechanical & Enviromental Data, See pg. 4 2002/95/EC RoHS 5,59 P LATING CODE = 10 0,25μm Au Fig. 6 Pin Plating w w w. m i l l - m a x . c o m 13  516-922-6000
