329-10-102-00-560000

INTERCONNECTS 2,54 Grid Surface Mount Headers and Sockets Single and Double Row 2,54 Number of Pins X 2,54 Series 329, 340, 414, 429 • Series 329 and 429 pin interconnects offer vertical Surface Mount MM #2956-X solder tails. See page 185 for details. • Series 340 Surface mount sockets use MM #4078 pins. Series 414 sockets use MM #1434 pins. See pages 133 and 138 for details. 0,46 DIA. 3,07 7,06 2,79 1,60 DIA. 0,46 2,54 Coplanarity 0,13. For Pin Counts >10 positions consult Technical Support. • Series 340 and 414 receptacles use HiRel, 4-finger BeCu #30 contacts rated at 3 amps. Receptacles accept 0,38 - 0,64 diameter pins. See page 218 for details. • Insulators are high temp. thermoplastic. Fig. 1 2002/95/EC RoHS 5,08 2,54 Number of Pins X 2,54 / 2 Ordering Information Series 329...560 Surface Mount Pin Header 0,46 DIA. 3,07 7,06 Fig. 1 2,54 329-10-1_ _-00-560000 Specify # of pins 02-64 Surface Mount Pin Header 2,79 0,97 DIA. 0,46 Series 429...560 Coplanarity 0,13. For Pin Counts >10 positions consult Technical Support. Fig. 2 429-10-2 _ _-00-560000 Specify # of pins 04-72 Fig. 2 0,38-0,64 0,25 * 0,46 5,08 Number of Pins X 2,54 / 2 For Electrical, Mechanical & Enviromental Data, See pg. 4 For RoHS compliance select  plating code. 2,44 0,97 DIA. 0,64 DIA. HOLE 2,54 2,79 4,22 PLATING CODE = 10 0,25μm Au Pin Plating 2,54 Series 414...117 Surface Mount Socket Coplanarity 0,13. For Pin Counts >10 positions consult Technical Support. Fig. 3 414-43-2 _ _-41-117000 Specify # of pins Series 340...780 04-72 Surface Mount Socket Fig. 3 Number of Pins X 2,54 0,38-0,64 0,25 * 0,46 2,54 2,11 4,37 2,79 5,08 2,29 Fig. 4 2,54 2,79 340-43-1 _ _-30-780100 Specify # of pins 02-64 For RoHS compliance select  plating code. 1,17 1,42 3,18 Footprint 3,3 For Electrical, Mechanical & Enviromental Data, See pg. 4 2,54 Coplanarity 0,13. For Pin Counts >10 positions consult Technical Support. PLATING CODE = 43  5,08µm Sn 0,76µm Au Fig. 4 Sleeve (Pin) Contact (Clip) w w w. m i l l - m a x . c o m 76  516-922-6000
