350-40-164-00-106000

INTERCONNECTS Series 310, 350 .100” Grid (.018” dia.) Pins SMT Gull Wing Headers & Sockets 410, 450 Single and Double Row Left Hand Footprint • Headers (350 & 450) use MM# 3404 pins. See page 179 for details. • Sockets (310 & 410) use MM# 1005 receptacles and accept pin diameters from .015-.025. See page 137 for details. Right Hand Footprint Coplanarity .005”. For Pin Counts > 10 Consult Tech Support Fig. 1 Footprint 2002/95/EC RoHS • Coplanarity .005” (Single Row max 10 pins; Double Row max 20 pins). For higher pin counts contact technical support. • Insulators are high temp. thermoplastic. For RoHS compliance select p lating code. Ordering Information XX=Plating Code See Below Single Row Header, Left Hand Footprint Odd or Even # of pins Fig. 1L Coplanarity .005”. For Pin Counts > 20 Consult Tech Support 350-XX-1_ _-00-106000 Specify # of pins 02-64 Single Row Header, Right Hand Footprint Even # of pins Fig. 2 Left Hand Footprint Fig. 1R 350-XX-1_ _-00-107000 Specify even # of pins 02-64 Double Row Header, Even # of pins Fig. 2 Right Hand Footprint SPECIFY PLATING CODE XX= 450-XX-2 _ _-00-106000 Specify even # of pins 10 90 04-72 40 Pin Plating Coplanarity .005”. For Pin Counts > 10 Consult Tech Support 10μ” Au 200μ” Sn/Pb 200μ” Sn Fig. 3 Footprint Single Row Socket, Left Hand Footprint Odd or Even # of pins Fig. 3L 310-43-1_ _-41-105000 Specify # of pins 02-64 Single Row Socket, Right Hand Footprint Even # of pins Fig. 3R 310-43-1_ _-41-107000 Specify even # of pins 02-64 Double Row Socket, Even # of pins Fig. 4 For Electrical, Mechanical & Enviromental Data, See pg. 4 410-43-2 _ _-41-105000 Specify even # of pins 04-72 99 200µ”Sn/Pb PLATING CODE = 13 30µ” Au 93 30µ” Au 43 44 Coplanarity .005”. For Pin Counts > 20 Consult Tech Support Sleeve (Pin) Contact (Clip) 10µ” Au 200µ” Sn/Pb 200µ”Sn/Pb 200µ”Sn 200µ”Sn 30µ” Au 200µ”Sn Fig. 4 w w w. m i l l - m a x . c o m 78 516-922-6000
