470-90-202-00-001000

HEADER STRIPS .100” Grid Solder Tail Double Row • Series 450, 460, 470 & 480 double row Header strips come with various styles (pin, slotted head, turret and solder cup) with pluggable solder tails. 450...001 uses pin #0290 460...001 uses pin #0282 470...001 uses pin #0700 480...001 uses pin #8000 See pages 182 & 183 for details. • Insulators are high temp. thermoplastic. 2002/95/EC Series 450, 460 470, 480 RoHS Ordering Information Fig. 1 Fig. 1 Series 450...001 Pin / Solder Tail 450-XX-2_ _-00-001000 Specify # of pins 02-64 Fig. 2 Series 460...001 Slotted Head / Solder Tail 460-10-2_ _-00-001000 Specify # of pins 02-64 Fig. 2 Fig. 3 Series 470...001 Turret / Solder Tail 470-XX-2_ _-00-001000 Specify # of pins Series 480...001 02-64 Solder Cup / Solder Tail 02-64 Fig. 4 480-10-2_ _-00-001000 Specify # of pins Fig. 3 For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below For RoHS compliance select p lating code. SPECIFY PLATING CODE XX= 10 10μ” Au 90 200μ” Sn/Pb 40 200μ” Sn Fig. 4 Pin Plating w w w. m i l l - m a x . c o m 109 516-922-6000
