480-10-102-00-001000

INTERCONNECTS 2,54 Grid Solder Cup Headers and Sockets Single and Double Row Number of Pins X 2,54 Series 329, 380, 429, 480 0,99 DIA. HOLE 1,83 DIA. 3,23 2,79 • Series 380 & 480 use MM #8000 pins. See page 183 for details. • Series 329 & 429 use MM #2954 pin receptacles and accept pin diameters from 0,38 - 0,64. See page 142 for details. • Series 329 & 429 receptacles use Hi-Rel, 4 finger BeCu #30 contacts rated at 3 amps. See page 218 for details. 3,15 0,51 DIA. 4,22 2,54 • Solder cups are pre-aligned. • Insulators are high temp. thermoplastic. 2002/95/EC RoHS Fig. 1 Ordering Information 0,99 DIA. HOLE 3,23 Number of Pins X 2,54 / 2 Series 380...001 2,79 3,15 Solder Cup / Solder Tail 1,83 DIA. Fig. 1 380-XX-1_ _-00-001000 Specify # of pins Series 480...001 01-64 Solder Cup / Solder Tail 0,51 DIA. 4,22 2,54 2,54 Fig. 2 Fig. 2 480-10-2 _ _-00-001000 Specify # of pins 02-64 0,38-0,64 0,25 * 0,46 Number of Pins X 2,54 2,54 For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below For RoHS compliance select  plating code. 2,54 2,79 3,81 7,37 SPECIFY PLATING CODE XX= 10 90 40 5,08μm Sn 1,35 DIA. Pin Plating 0,25μm Au 5,08μm Sn/Pb 1,52 2,29 0,97 DIA. HOLE Series 329...540 2,54 Solder Cup Sockets Fig. 3 329-43-1 _ _-41-540000 Specify # of pins Series 429...540 01-64 Solder Cup Sockets Fig. 3 0,38-0,64 0,25 * 0,46 5,08 Number of Pins X 2,54 / 2 Fig. 4 429-43-2 _ _-41-540000 Specify # of pins 02-64 For RoHS compliance select  plating code. 2,54 2,79 3,81 7,37 1,35 DIA. 1,52 2,29 0,97 DIA. HOLE For Electrical, Mechanical & Enviromental Data, See pg. 4 2,54 2,54 PLATING CODE = 13  93 43  5,08µm Sn 0,76µm Au Fig. 4 Sleeve (Pin) Contact (Clip) w w w. m i l l - m a x . c o m 75  516-922-6000
