800-90-064-62-001000

INTERCONNECTS .100” Grid (.030” dia.) Pins, Solderless Press-Fit Single Row • The unique compliant tail pins conform to .040”+.003” finished hole without stressing inner layers. Patent No. 4,799,904 • Series 800 pin headers are offered in two tail lengths for .060”-.100” (MM #5601) and .090”-.130” (MM #5602) thick panels. See page 187 for details. • Series 801 sockets MM #4614 or #4615 use Hi-Rel, 6-finger BeCu #47 contacts rated at 4.5 amps. Receptacles accept .030” diameter pins & .025” square pins. See page 221 for details. Series 800, 801 Fig. 1 • Insulators are high temp. thermoplastic. 2002/95/EC RoHS Ordering Information Compliant Tail Pin Header for .060 - .100” thick boards Fig. 1 800-XX-0 _ _-61-001000 Specify # of pins 01-64 Compliant Tail Pin Header for .090 - .130” thick boards Fig. 2 Fig. 2 800-XX-0 _ _-62-001000 Specify # of pins 01-64 For RoHS compliance select p lating code. For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below SPECIFY PLATING CODE XX= 10 10μ” Au 90 200μ” Sn/Pb 40 200μ” Sn Pin Plating Compliant Tail Socket for .060 - .100” thick boards Fig. 3 Fig. 3 801-XX-0 _ _-61-001000 Specify # of pins 01-50 Compliant Tail Socket for .090 - .130” thick boards Fig. 4 801-XX-0 _ _-62-001000 Specify # of pins 01-50 For RoHS compliance select p lating code. For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below S PECIFY PLATING CODE XX= 13 10µ” Au 30µ” Au 91 10µ” Au 93 30µ” Au 99 200µ”Sn/Pb 41 10µ” Au 43 44 Sleeve (Pin) 200µ” Sn/Pb 200µ” Sn/Pb 200µ”Sn/Pb 200µ”Sn 200µ”Sn 200µ”Sn 30µ” Au 200µ”Sn Fig. 4 Contact (Clip) w w w. m i l l - m a x . c o m 83 516-922-6000
