803-93-004-30-001000

INTERCONNECTS Series 800, 801, .100” Grid (.030” dia.) Pins, Surface Mount Headers & Sockets 802, 803 Single and Double Row .100 Number of Pins X .100" .030 DIA. • Series 800 & 802 use MM #7007 pins. See page 182 for details. • Series 801 & 803 use MM #1304 receptacles and accept pin diameters from .025”-.037” and .025” square pins. See page 148 for details. • Receptacles use Hi-Rel, 6 finger BeCu #47 contact rated at 4.5 amps. See page 221 for details. .200 .195 .176 .110 .175 .100 .100 Coplanarity .005”. For Pin Counts >10 positions consult Technical Support. .045 Fig. 1 .200 • Insulators are high temp. thermoplastic. Number of Pins X .100" / 2 2002/95/EC RoHS .200 .100 Ordering Information 800...001 .110 .030 DIA. .195 Single Row Surface Mount Header 800-10-0_ _-30-001000 .176 Fig. 1 802...001 Specify # of pins .285 .100 .100 03-64 Coplanarity .005”. For Pin Counts >20 positions consult Technical Support. .045 Double Row Surface Mount Header 802-10-0_ _-30-001000 .100 Fig. 2 Fig. 2 .025-.037 .025 * .025 .100 .300 Specify # of pins 04-72 Number of Pins X .100" .088 .240 .276 For Electrical, Mechanical & Enviromental Data, See pg. 4 .338 For RoHS compliance select p lating code. PLATING CODE = 10 10μ” Au 90 200μ” Sn/Pb 40 200μ” Sn Pin Plating .170 .100 .100 Coplanarity .005”. For Pin Counts >10 positions consult Technical Support. 801...001 Single Row Surface Mount Socket 801-43-0 _ _-30-001000 Fig. 3 .045 .200 Fig. 3 .025-.037 .025 * .025 .200 Specify # of pins 803...001 03-50 Double Row Surface Mount Socket 803-XX-_ _ _-30-001000 .200 .100 Number of Pins X .100" / 2 Fig. 4 .088 .240 .276 .338 Specify # of pins For Electrical, Mechanical & Enviromental Data, See pg. 4 004-100 For RoHS compliance select p lating code. .272 .100 .100 XX=Plating Code See Below Coplanarity .005”. For Pin Counts >20 positions consult Technical Support. .045 .100 S PECIFY PLATING CODE XX= 13 10µ” Au 30µ” Au 10µ” Au 93 200µ” Sn/Pb 30µ” Au 43 200µ”Sn 30µ” Au Sleeve (Pin) Fig. 4 .290 Contact (Clip) w w w. m i l l - m a x . c o m 85 516-922-6000
