803-93-072-10-002000

INTERCONNECTS Series 800, 801 .100” Grid (.030” dia.) Low Profile Headers & Versatile Sockets 802, 803 Single and Double Row • Series 800 and 802 single and double row pin headers use MM #5016 pins. See page 182 for details. Series 801 and 803 single and double row sockets use MM #1303 pins. See page 150 for details. Series 801 and 803 receptacles use Hi-Rel, 6-finger BeCu #47 contacts rated at 4.5 amps. Receptacles accept .025” diameter and .025” square pins. See page 221 for details. Insulators are high temp. thermoplastic. • • Fig. 1 • 2002/95/EC RoHS Ordering Information Single Row Low Profile Pin Header 800-XX-0_ _-10-002000 Specify # of pins Fig. 2 Fig. 1 Double Row 01-64 Low Profile Pin Header Fig. 2 802-XX-0 _ _-10-002000 Specify # of pins 02-64 For RoHS compliance select p lating code. For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below SPECIFY PLATING CODE XX= 10 10μ” Au 90 200μ” Sn/Pb 40 200μ” Sn Fig. 3 Pin Plating Single Row Low Profile Socket (short insulator) 801-XX-0 _ _-10-002000 01-64 Fig. 3 Single Row Specify # of pins Fig. 4 Fig. 4 Low Profile Socket (long insulator) 801-XX-0 _ _-10-012000 01-36 Specify # of pins Fig. 5 Double Row Low Profile Socket 803-XX-0 _ _-10-002000 Specify # of pins 02-72 For RoHS compliance select p lating code. For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below SPECIFY PLATING CODE XX= 13 10µ” Au 30µ” Au 91 10µ” Au 93 30µ” Au 99 200µ”Sn/Pb 41 10µ” Au 43 44 Sleeve (Pin) 200µ” Sn/Pb 200µ” Sn/Pb 200µ”Sn/Pb 200µ”Sn 200µ”Sn 200µ”Sn 30µ” Au 200µ”Sn Fig. 5 Contact (Clip) w w w. m i l l - m a x . c o m 80 516-922-6000
