830-10-001-10-001000

INTERCONNECTS 2mm Grid Headers and Sockets Single and Double Row • Series 830 single and double row interconnects have 2mm pin spacing and permit board stacking as low as .322”. • Pin headers (830 & 832 series) use MM #5012 pins. See page 175 for details. • Sockets (831 & 833 series) use MM #1802 receptacles and accept pin diameters from .015”-.025”. See page 140 for details. • Insulators are high temp. thermoplastic, suitable for all soldering operations. Series 830, 831 832, 833 2002/95/EC RoHS Fig. 1 Ordering Information Single Row Pin Header Fig. 1 830-XX-0_ _-10-001000 Specify # of pins 01-50 Double Row Pin Header Fig. 2 Fig. 2 832-XX-_ _ _-10-001000 Specify # of pins 002-100 For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below For RoHS compliance select p lating code. SPECIFY PLATING CODE XX= 10 10μ” Au 90 200μ” Sn/Pb 40 200μ” Sn Pin Plating Single Row Socket Fig. 3 Fig. 3 831-XX-0_ _-10-001000 Specify # of pins 01-50 Double Row Socket Fig. 4 833-XX-_ _ _-10-001000 Specify # of pins 002-100 For RoHS compliance select p lating code. For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below SPECIFY PLATING CODE XX= 13 10µ” Au 30µ” Au 91 10µ” Au 93 30µ” Au 99 200µ”Sn/Pb 41 10µ” Au 43 44 Fig. 4 Sleeve (Pin) Contact (Clip) 200µ” Sn/Pb 200µ” Sn/Pb 200µ”Sn/Pb 200µ”Sn 200µ”Sn 200µ”Sn 30µ” Au 200µ”Sn w w w. m i l l - m a x . c o m 70 516-922-6000
