830-10-002-30-002000

厂商：
MILL-MAX
封装：
描述：
830-10-002-30-002000 - INTERCONNECTS 2mm Grid Surface Mount Headers And Sockets Single and Double Ro...

数据手册：

下载830-10-002-30-002000.pdf

立即购买

详情介绍
数据手册
价格&库存

830-10-002-30-002000 数据手册

INTERCONNECTS 2mm Grid Surface Mount Headers And Sockets Single and Double Row Left Hand Footprint Series 830, 831 832, 833 • Headers (830 & 832) use MM# 6218 pins. See page 175 for details. • Sockets (831 & 833) use MM# 1802 receptacles and accept pin diameters from .015-.025. See page 140 for details. Right Hand Footprint Coplanarity .005”. For Pin Counts > 12 Consult Tech Support 2002/95/EC RoHS Fig. 1 Footprint • Coplanarity .005” (Single Row max 12 pins; Double Row max 24 pins) for higher pin counts contact technical support. • Insulators are high temp. thermoplastic. For RoHS compliance select p lating code. Ordering Information XX=Plating Code See Below Coplanarity .005”. For Pin Counts > 24 Consult Tech Support Single Row Header, Left Hand Footprint Odd or Even # of pins Fig. 1L 830-XX-0_ _-30-001000 Specify # of pins 01-50 Single Row Header, Right Hand Footprint Even # of pins Fig. 2 Left Hand Footprint Fig. 1R 830-XX-0_ _-30-002000 Specify even # of pins 02-50 Double Row Header, Even # of pins Fig. 2 Right Hand Footprint 832-XX-_ _ _-30-001000 Specify even # of pins 004-100 90 40 10 SPECIFY PLATING CODE XX= Pin Plating Coplanarity .005”. For Pin Counts > 12 Consult Tech Support 10μ” Au 200μ” Sn/Pb 200μ” Sn Fig. 3 Footprint Single Row Socket, Left Hand Footprint Odd or Even # of pins Fig. 3L 831-XX-0_ _-30-001000 Specify # of pins 01-50 Single Row Socket, Right Hand Footprint Even # of pins Fig. 3R 831-XX-0_ _-30-002000 Specify even # of pins 02-50 Double Row Socket, Even # of pins Fig. 4 For Electrical, Mechanical & Enviromental Data, See pg. 4 833-XX-_ _ _-30-001000 Specify even # of pins 004-100 99 200µ”Sn/Pb SPECIFY PLATING CODE XX= 13 30µ” Au 93 30µ” Au 43 44 Coplanarity .005”. For Pin Counts > 24 Consult Tech Support Sleeve (Pin) Contact (Clip) 10µ” Au 200µ” Sn/Pb 200µ”Sn/Pb 200µ”Sn 200µ”Sn 30µ” Au 200µ”Sn Fig. 4 w w w. m i l l - m a x . c o m 71 516-922-6000

下载 PDF

830-10-002-30-002000

### 物料型号 - Series 830, 831, 832, 833：这些系列编号指的是2mm间距的表贴式排母和排针，包括单排和双排。

### 器件简介 - 2mm Grid Surface Mount Headers And Sockets Single and Double Row：描述了器件为2mm间距的表面贴装式排母和排针，有单排和双排两种类型。

### 引脚分配 - Headers (830& 832)：使用MM#6218引脚，具体详情见第175页。 - Sockets (831 & 833)：使用MM#1802插座，接受引脚直径从0.015到0.025不等，具体详情见第140页。

### 参数特性 - Coplanarity：0.005，对于单排最多12个引脚；双排最多24个引脚。对于更高的引脚数量，请联系技术支持。

### 功能详解和应用信息 - Insulators are high temp. thermoplastic：绝缘体是高温热塑性材料。 - For RoHS compliance select plating code：为符合RoHS合规性，请选择镀层代码。

### 封装信息 - Single Row Header, Left Hand Footprint：单排左侧引脚，奇数或偶数个引脚，型号为830-XX-0_-30-001000。 - Single Row Header, Right Hand Footprint：单排右侧引脚，偶数个引脚，型号为830-XX-0 -30-002000。 - Double Row Header, Even #of pins：双排引脚，偶数个引脚，型号为832-XX-30-001000。 - Single Row Socket, Left Hand Footprint：单排左侧插座，奇数或偶数个引脚，型号为831-XX-0 -30-001000。 - Single Row Socket, Right Hand Footprint：单排右侧插座，偶数个引脚，型号为831-XX-0 -30-002000。 - Double Row Socket, Even #of pins：双排插座，偶数个引脚，型号为833-XX-30-001000。
