830-90-050-30-002000

INTERCONNECTS 2mm Grid Surface Mount Headers And Sockets Single and Double Row Left Hand Footprint Series 830, 831 832, 833 • Headers (830 & 832) use MM# 6218 pins. See page 175 for details. • Sockets (831 & 833) use MM# 1802 receptacles and accept pin diameters from .015-.025. See page 140 for details. Right Hand Footprint Coplanarity .005”. For Pin Counts > 12 Consult Tech Support 2002/95/EC RoHS Fig. 1 Footprint • Coplanarity .005” (Single Row max 12 pins; Double Row max 24 pins) for higher pin counts contact technical support. • Insulators are high temp. thermoplastic. For RoHS compliance select p lating code. Ordering Information XX=Plating Code See Below Coplanarity .005”. For Pin Counts > 24 Consult Tech Support Single Row Header, Left Hand Footprint Odd or Even # of pins Fig. 1L 830-XX-0_ _-30-001000 Specify # of pins 01-50 Single Row Header, Right Hand Footprint Even # of pins Fig. 2 Left Hand Footprint Fig. 1R 830-XX-0_ _-30-002000 Specify even # of pins 02-50 Double Row Header, Even # of pins Fig. 2 Right Hand Footprint 832-XX-_ _ _-30-001000 Specify even # of pins 004-100 90 40 10 SPECIFY PLATING CODE XX= Pin Plating Coplanarity .005”. For Pin Counts > 12 Consult Tech Support 10μ” Au 200μ” Sn/Pb 200μ” Sn Fig. 3 Footprint Single Row Socket, Left Hand Footprint Odd or Even # of pins Fig. 3L 831-XX-0_ _-30-001000 Specify # of pins 01-50 Single Row Socket, Right Hand Footprint Even # of pins Fig. 3R 831-XX-0_ _-30-002000 Specify even # of pins 02-50 Double Row Socket, Even # of pins Fig. 4 For Electrical, Mechanical & Enviromental Data, See pg. 4 833-XX-_ _ _-30-001000 Specify even # of pins 004-100 99 200µ”Sn/Pb SPECIFY PLATING CODE XX= 13 30µ” Au 93 30µ” Au 43 44 Coplanarity .005”. For Pin Counts > 24 Consult Tech Support Sleeve (Pin) Contact (Clip) 10µ” Au 200µ” Sn/Pb 200µ”Sn/Pb 200µ”Sn 200µ”Sn 30µ” Au 200µ”Sn Fig. 4 w w w. m i l l - m a x . c o m 71 516-922-6000
