850-10-001-10-001000

INTERCONNECTS .050” Grid Headers and Sockets Single and Double Row (Number of Pins X .050”) + .015” Series 850, 851 852, 853 • Series 850 single and double row interconnects have .050” pin spacing & permit board stacking as low as .248”. • Pin headers have .016” dia. pins ( MM #4006-0 ). See page 175 for details. • MM #0467 and MM #4890 receptacles use Hi-Rel, 3-finger BeCu #11 contacts rated at 3 amps. ( #11 contact accepts pin diameters from .015”-.020” ). See pages 129 and 131 for details. • Insulators are high temp. thermoplastic, suitable for all soldering operations. 2002/95/EC Fig. 1 (Number of Pins X .050”/2) + .015” RoHS Ordering Information Single Row .087” Profile Pin Header 850-XX-0_ _-10-001000 Specify # of pins Fig. 2 (Number of Pins X .050”) + .015” Fig. 1 01-50 .075” Profile Pin Header Double Row Fig. 2 852-XX-_ _ _-10-001000 Specify # of pins 002-100 For RoHS compliance select p lating code. For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below SPECIFY PLATING CODE XX= 10 10μ” Au 90 200μ” Sn/Pb 40 200μ” Sn Fig. 3 (Number of Pins X .050”/2) + .015” Pin Plating Single Row .161” Profile Socket 851-XX-0_ _-10-001000 01-50 .161” Profile Socket 002-100 .185” Profile Socket 851-XX-0_ _-10-002000 01-77 For RoHS compliance select p lating code. Fig. 3 Specify # of pins Double Row Fig. 4 Fig. 4 (Number of Pins X .050”) + .040” 853-XX-_ _ _-10-001000 Specify # of pins Single Row Fig. 5 Specify # of pins For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below SPECIFY PLATING CODE XX= 13 10µ” Au 30µ” Au 91 10µ” Au 93 30µ” Au 99 200µ”Sn/Pb 41 10µ” Au 43 44 Sleeve (Pin) 200µ” Sn/Pb 200µ” Sn/Pb 200µ”Sn/Pb 200µ”Sn 200µ”Sn 200µ”Sn 30µ” Au 200µ”Sn Fig. 5 Contact (Clip) w w w. m i l l - m a x . c o m 66 516-922-6000
