850-10-004-30-001000

INTERCONNECTS .050” Grid Surface Mount Headers and Sockets Single and Double Row For RoHS compliance select p lating code. (Number of Pins X .050”) + .015” Series 850, 851 852, 853 Left Hand Footprint Right Hand Footprint Coplanarity .005”. For Pin Counts > 20 Consult Tech Support Fig. 1 Footprint (Number of Pins X .050”/2) + .015” • Single row interconnects having an even number of pins are now available with a left or right hand footprint. • Headers (850 & 852) use MM# 4006 pins. See page 175 for details. • Sockets (851 & 853) RoHS 2002/95/EC use MM# 4890-0 receptacles and accept pin diameters from .015-.021. See page 131 for details. • Coplanarity .005” (Single Row max 20 pins; Double Row max 40 pins). For higher pin counts contact techical support . • Insulators are high temp. thermoplastic. Ordering Information Coplanarity .005”. For Pin Counts > 40 Consult Tech Support XX=Plating Code See Below Single Row Header, Left Hand Footprint Odd or Even # of pins Fig. 1L 850-XX-0_ _-30-001000 Specify # of pins 01-50 Single Row Header, Right Hand Footprint Even # of pins Fig. 2 Left Hand Footprint (Number of Pins X .050”) + .015” Fig. 1R 850-XX-0_ _-30-002000 Specify even # of pins 02-50 Double Row Header, Even # of pins Right Hand Footprint Fig. 2 SPECIFY PLATING CODE XX= 852-XX-_ _ _-30-001000 Specify even # of pins 10 90 004-100 40 Coplanarity .005”. For Pin Counts > 20 Consult Tech Support Pin Plating 10μ” Au 200μ” Sn/Pb 200μ” Sn Fig. 3 Footprint (Number of Pins X .050”/2) + .015” Single Row Socket, Left Hand Footprint Odd or Even # of pins Fig. 3L 44 Plating Non-Standard 851-XX-0_ _-30-001000 Fig. 3R Specify # of pins 01-50 Single Row Socket, Right Hand Footprint Even # of pins 851-XX-0_ _-30-002000 Specify even # of pins 02-50 Double Row Socket, Even # of pins Fig. 4 Coplanarity .005”. For Pin Counts > 40 Consult Tech Support For Electrical, Mechanical & Enviromental Data, See pg. 4 44 Plating Non-Standard 853-XX-_ _ _-30-001000 004-100 99 200µ”Sn/Pb Specify even # of pins SPECIFY PLATING CODE XX= 13 30µ” Au 93 30µ” Au 43 44 Sleeve (Pin) 10µ” Au 200µ” Sn/Pb 200µ”Sn/Pb 200µ”Sn 200µ”Sn 30µ” Au 200µ”Sn Fig. 4 w w w. m i l l - m a x . c o m Contact (Clip) 68 516-922-6000
