852-10-100-20-001000

INTERCONNECTS .050” Grid Right Angle Headers and Sockets Single and Double Row • Series 850 and 851 interconnects are Series 850, 851 852, 853 available in single and double row form. (Number of Pins X .050”) + .015” • 850 & 852 series headers use MM #4006-1 and #4006-2 pins. See page 175 details. • 851 & 853 series sockets use MM #4890-1 and #4890-2 receptacles, that accept pin diameters from .015”-.021” See page 131 for details. Fig. 1 • Insulators are high temp. thermoplastic. 2002/95/EC RoHS Ordering Information (Number of Pins X .050”/2) + .015” Single Row Right Angle Pin Header 850-XX-0_ _-20-001000 Fig. 1 Double Row Fig. 2 Specify # of pins 01-50 Right Angle Pin Header Fig. 2 852-XX-_ _ _-20-001000 Specify # of pins 002-100 (Number of Pins X .050”) + .015” For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below For RoHS compliance select p lating code. SPECIFY PLATING CODE XX= 10 10μ” Au 90 200μ” Sn/Pb 40 200μ” Sn Pin Plating Single Row Right Angle Socket 851-XX-0_ _-20-001000 Fig. 3 Fig. 3 Specify # of pins Double Row 01-50 Right Angle Socket (Number of Pins X .050”/2) + .015” Fig. 4 853-XX-_ _ _-20-001000 Specify # of pins 002-100 For RoHS compliance select p lating code. For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below SPECIFY PLATING CODE XX= 13 10µ” Au 30µ” Au 91 10µ” Au 93 30µ” Au 99 200µ”Sn/Pb 41 10µ” Au 43 44 Fig. 4 Sleeve (Pin) Contact (Clip) 200µ” Sn/Pb 200µ” Sn/Pb 200µ”Sn/Pb 200µ”Sn 200µ”Sn 200µ”Sn 30µ” Au 200µ”Sn w w w. m i l l - m a x . c o m 67 516-922-6000
