870-10-002-20-001000

INTERCONNECTS Series 870, 871 .070” Grid (.018” dia.) Pins, Right Angle Headers & Sockets Single Row Number of Pins X .070"+.012" .104 .052 (TYP) • Series 870 use MM #3790-0 pins. See page 176 for details. • Series 871 use MM #1805 receptacles and accept pin diameters from .015” .025”. See page 140 for details. • Receptacles use Hi-Rel, 6 finger BeCu #43 contact rated at 3 amps. See page 220 for details. • Insulators are high temp. thermoplastic. 2002/95/EC .070 .133 .110 Number of Pins X .070 + .012 .104 .018 DIA. .112 RoHS .220 .070 Fig. 1 Number of Pins X .070"+.012" .104 .052 (TYP) Ordering Information Series 870...20-001 Right Angle Pin Header Fig. 1 870-10-0_ _-20-001000 Specify # of pins 02-21 .070 .165 .145 .110 Number of Pins X .070 + .012 .052 .018 DIA. .104 .122 .220 .070 For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below For RoHS compliance select  plating code. Fig. 2 SPECIFY PLATING CODE XX= 10 10μ” Au Pin Plating Series 871...20-001 Right Angle Socket Fig. 2 871-43-0_ _-20-001000 Specify # of pins 02-21 For Electrical, Mechanical & Enviromental Data, See pg. 4 XX=Plating Code See Below For RoHS compliance select  plating code. PLATING CODE = 13  10µ” Au 30µ” Au 10µ” Au 93 200µ” Sn/Pb 30µ” Au 43  200µ”Sn 30µ” Au Sleeve (Pin) Contact (Clip) w w w. m i l l - m a x . c o m 69.1  516-922-6000
