890-90-002-20-902

INTERCONNECTS .025” Square Pin Headers Single and Double Row • Square pin headers may be used as board-to-board interconnects using series 801, 803 socket strips; or as a hardware programming switch with series 999 color coded jumpers. Single and double row strips are available with straight or right angle solder tails. Series 890, 892 • • Current rating is 1 amp. • Insulator is std. temp. thermoplastic. TAIL LENGTH LENGTH OF SELECTIVE GOLD PIN LENGTH Ordering Information Single Row Fig.1 Vertical Mount 890-XX-XXX-10-802 890-XX-XXX-10-803 890-XX-XXX-10-805 890-XX-XXX-10-806 890-XX-XXX-10-807 890-XX-XXX-10-808 890-XX-XXX-10-800 890-XX-XXX-10-809 Single Row Fig.3 Right Angle Double Row Fig.2 Vertical Mount 892-XX-XXX-10-802 892-XX-XXX-10-803 892-XX-XXX-10-805 892-XX-XXX-10-806 892-XX-XXX-10-807 892-XX-XXX-10-808 892-XX-XXX-10-800 892-XX-XXX-10-809 Double Row Fig.4 Right Angle 892-XX-XXX-20-902 A .230 .235 .230 .230 .230 .230 .265 .335 B .100 .120 .205 .305 .405 .505 .135 .100 G min. .180 .180 .180 .180 .180 .180 .215 .285 .230 .115 .180 890-XX-XXX-20-902 Specify number of pins XXX: From 002 To 036 Specify total no. of pins XXX: From 004 (2x2) To 072 (2x36) XX= Plating Code See Below SPECIFY PLATING CODE XX= 19 10µ” Au 39 30µ” Au 90 150µ” Sn/Pb Pin (Dim ‘A’) Tail (Dim ‘B’) 150µ” Sn/Pb 150µ” Sn/Pb 150µ” Sn/Pb Mill-Max-Mfg.Corp., P.O. Box 300, 190 Pine Hollow Road, Oyster Bay, NY 11771-0300.Tel: 516-922-6000 Fax: 516-922-9253 85
