ADC-6-10-75

Directional Coupler 75Ω 20 to 1000 MHz Features -40°C to 85°C -55°C to 100°C Surface Mount ADC-6-10-75+ ADC-6-10-75 Maximum Ratings Operating Temperature Storage Temperature Permanent damage may occur if any of these limits are exceeded. Pin Connections INPUT OUTPUT COUPLED GROUND 75Ω TERM EXTERNAL ISOLATE (DO NOT USE) 1 6 3 2 4 5 • wideband, 20 to 1000 MHz • low mainline loss, 2.1 dB typ. • excellent coupling flatness, ±0.15 typ. • aqueous washable • protected by U.S Patents 6,133,525 & 6,140,887 CASE STYLE: CD542 PRICE: $6.95 ea. QTY (10-49) + RoHS compliant in accordance with EU Directive (2002/95/EC) The +Suffix identifies RoHS Compliance. See our web site for RoHS Compliance methodologies and qualifications. Applications • cable tv Directional Coupler Electrical Specifications FREQ. (MHz) COUPLING (dB) MAINLINE LOSS1 (dB) L Typ. Max. 2.1 2.8 M Typ. Max. 2.1 2.5 U Typ. Max. 2.2 2.8 L Typ. Min. 15 12 Outline Drawing DIRECTIVITY (dB) M Typ. Min. 15 12 U Typ. Min. 15 9 VSWR POWER (:1) INPUT, W L Max. 0.5 MU Max. 0.5 fL-fU 20-1000 Nom. 6.6±0.5 Flatness ±0.5 Typ. 1.33 L= 20-200 MHz M= 200-500 MHz U= 500-1000 MHz 1. Mainline loss includes theoretical power loss at coupled port. Typical Performance Data PCB Land Pattern Frequency (MHz) 18.00 50.00 100.00 300.00 500.00 Mainline Loss (dB) In-Out 2.12 2.14 2.14 2.09 2.11 2.16 2.23 2.27 2.25 2.26 ADC-6-10-75 INSERTION LOSS Coupling (dB) In-Cpl 6.65 6.66 6.70 6.72 6.53 6.48 6.51 6.61 6.67 6.70 Directivity (dB) 15.82 15.80 15.73 15.71 15.84 15.88 15.88 15.59 14.91 13.81 In 15.10 15.28 15.50 17.25 20.57 22.66 24.28 24.45 24.18 24.01 Return Loss (dB) Out 36.74 49.03 38.41 27.75 24.15 23.38 23.33 23.80 24.25 23.70 Cpl 15.09 15.44 15.43 16.06 19.74 17.89 18.52 22.73 21.44 19.57 Suggested Layout, Tolerance to be within ±.002 � Outline Dimensions ( inch ) mm A .272 6.91 H .030 0.76 B .310 7.87 J .026 0.66 C .220 5.59 K .065 1.65 D .100 2.54 L .300 7.62 E .112 2.84 F .055 1.40 G .100 2.54 INSERTION LOSS (dB) 2.5 2.4 2.3 2.2 2.1 2.0 600.00 700.00 800.00 900.00 1000.00 ADC-6-10-75 COUPLING & DIRECTIVITY 30 COUPLING & DIRECTIVITY (dB) 24 18 12 6 0 at RF level of -10 dBm at RF level of -10 dBm wt grams 0.20 COUPLING DIRECTIVITY Demo Board MCL P/N: TB-08 Suggested PCB Layout (PL-042) 0 200 400 600 FREQUENCY (MHz) 800 1000 0 200 400 600 FREQUENCY (MHz) 800 1000 ADC-6-10-75 RETURN LOSS 70 RETURN LOSS (dB) 60 50 40 30 20 10 0 0 200 400 600 FREQUENCY (MHz) 800 1000 at RF level of -10 dBm Electrical Schematic CPL IN OUT Mini-Circuits TM ® minicircuits.com ISO 9001 ISO 14001 AS 9100 CERTIFIED P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site The Design Engineers Search Engine Provides ACTUAL Data Instantly From MINI-CIRCUITS At: www.minicircuits.com IF/RF MICROWAVE COMPONENTS REV. D M119986 ED-7094/1 ADC-6-10-75 WZ/TD/CP/AM 081111
