ADC-6-13

Surface Mount Directional Coupler 50Ω 200 to 1300 MHz Features -40°C to 85°C -55°C to 100°C ADC-6-13+ ADC-6-13 Maximum Ratings Operating Temperature Storage Temperature Pin Connections INPUT OUTPUT COUPLED GROUND 50Ω TERM EXTERNAL GROUND or NO CONNECTION 1 6 3 2 4 5 • wideband, 200-1300 MHz • excellent VSWR. 1:3:1 typ. • excellent coupling flatness, ±0.5 typ. • aqueous washable • protected by U.S Patents 6,133,525 & 6,140,887 CASE STYLE: CD542 PRICE:$6.95 ea. QTY (10-49) + RoHS compliant in accordance with EU Directive (2002/95/EC) The +Suffix identifies RoHS Compliance. See our web site for RoHS Compliance methodologies and qualifications. Applications • cellular • VHF/UHF receivers Directional Coupler Electrical Specifications FREQ. (MHz) COUPLING (dB) MAINLINE LOSS1 (dB) DIRECTIVITY (dB) VSWR POWER (:1) INPUT, W Outline Drawing fL-fU 200-1300 Nom. 6.2±0.5 Flatness ±0.9 Typ. 1.8 Max. 2.5 Typ. 17 Min. 10 Typ. 1.3 L Max. 0.5 MU Max. 0.5 1. Mainline loss includes theoretical power loss at coupled port. Typical Performance Data PCB Land Pattern Frequency (MHz) 200.00 400.00 500.00 600.00 700.00 Mainline Loss (dB) In-Out 1.63 1.57 1.56 1.59 1.64 1.76 1.85 1.95 2.05 2.16 ADC-6-13 MAINLINE LOSS Coupling (dB) In-Cpl 6.78 6.77 6.70 6.61 6.52 6.29 6.20 6.11 6.04 5.98 Directivity (dB) In 15.32 16.43 16.81 17.19 17.56 18.16 18.24 18.05 17.55 16.79 16.16 19.27 20.80 22.02 22.08 20.57 19.80 18.83 17.57 16.32 Return Loss (dB) Out 16.80 20.03 20.81 21.37 21.46 20.96 21.45 19.86 19.28 18.80 Cpl 16.37 18.22 18.74 18.95 19.14 20.03 20.54 21.08 21.80 22.81 Suggested Layout, Tolerance to be within ±.002 Outline Dimensions ( inch ) mm A .272 6.91 H .030 0.76 B .310 7.87 J .026 0.66 C .220 5.59 K .065 1.65 D .100 2.54 L .300 7.62 E .112 2.84 F .055 1.40 G .100 2.54 INSERTION LOSS (dB) 2.5 2.3 2.1 1.9 1.7 900.00 1000.00 1100.00 1200.00 1300.00 ADC-6-13 COUPLING & DIRECTIVITY 25 COUPLING & DIRECTIVITY (dB) 20 15 10 5 0 200 at RF level of -10 dBm at RF level of -10 dBm wt grams 0.20 COUPLING DIRECTIVITY Demo Board MCL P/N: TB-05 Suggested PCB Layout (PL-041) 1.5 200 420 640 860 FREQUENCY (MHz) 1080 1300 420 640 860 FREQUENCY (MHz) 1080 1300 ADC-6-13 RETURN LOSS 30 RETURN LOSS (dB) 26 22 18 at RF level of -10 dBm electrical schematic CPL INPUT OUTPUT IN OUT COUPLED TERMINATE 14 10 200 420 640 860 FREQUENCY (MHz) 1080 1300 Mini-Circuits ISO 9001 ISO 14001 CERTIFIED RF/IF MICROWAVE COMPONENTS ® EW ALL N minicircuits.com REV. C M112428 ED-8270/1 ADC-6-13 WZ/TD/CP/AM 070920 P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site The Design Engineers Search Engine Provides ACTUAL Data Instantly From MINI-CIRCUITS At: www.minicircuits.com
