SK-2

Doubler Frequency Multiplier 50Ω Output 2 to 1000 MHz Features -55°C to 100°C -55°C to 100°C 200mW SK-2+ SK-2 Maximum Ratings Operating Temperature Storage Temperature RF Input Power • wideband, 2 to 1000 MHz • low conversion loss, 13.5 dB typ. CASE STYLE: B02 PRICE: $28.70 ea. QTY (1-9) Applications Pin Connections INPUT OUTPUT GROUND EXT. CASE GROUND ^ pins must be connected together externally • synthesizers • local oscillators 1,2^ 4 3 3 + RoHS compliant in accordance with EU Directive (2002/95/EC) The +Suffix identifies RoHS Compliance. See our web site for RoHS Compliance methodologies and qualifications. Frequency Multiplier Electrical Specifications MULTIPLICATION FACTOR FREQUENCY (MHz) Input Output 2-200 200-600 600-1000 INPUT POWER CONVERSION LOSS (dBm) (dB) Min. 1 1 1 Max. 10 10 10 Typ. 13.0 13.5 14.0 Max. 15.0 15.5 16.0 Typ. 40 25 20 *HARMONIC OUTPUT (dBc) F1 Min. 30 20 15 Typ. 50 40 30 F3 Min. 40 30 25 Typ. 16 16 16 F4 Min. 12 12 12 Outline Drawing 2 1-100 100-300 300-500 * Harmonic output below power level of F2 Typical Performance Data Output Frequency (MHz) 2.00 10.00 20.00 50.00 100.00 Conversion Loss (dB) F1 13.72 12.35 12.29 12.34 12.47 12.35 12.26 12.94 13.94 13.88 50.00 50.80 57.70 51.00 47.20 41.80 33.40 35.60 34.00 38.20 Harmonic Output (-dBc) F3 58.00 57.00 64.00 64.00 60.80 55.20 50.00 53.60 34.50 32.50 F4 13.90 15.00 18.00 18.50 18.70 18.90 20.80 22.00 24.40 29.60 Outline Dimensions ( inch ) mm A B .480 .500 12.19 12.70 G H .16 .100 4.06 2.54 C .240 6.10 J .14 3.56 D .255 6.48 K .20 5.08 E F .210 .230 5.33 5.84 L wt .020 grams 1.9 0.51 14.4 CONVERSION LOSS (dB) 14.0 13.6 13.2 12.8 12.4 12.0 0 200.00 400.00 600.00 800.00 1000.00 SK-2 CONVERSION LOSS 100 HARMONIC OUTPUT (-dBc) SK-2 HARMONIC OUTPUT F1 F3 F4 80 60 40 20 0 200 400 600 800 1000 0 200 400 600 800 1000 OUTPUT FREQUENCY (MHz) OUTPUT FREQUENCY (MHz) Mini-Circuits ISO 9001 ISO 14001 CERTIFIED RF/IF MICROWAVE COMPONENTS ® minicircuits.com REV. A M98898 SK-2 AD/CP 070305 EW ALL N P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site The Design Engineers Search Engine Provides ACTUAL Data Instantly From MINI-CIRCUITS At: www.minicircuits.com
