SM-BF-6

Adaptenuators 50Ω, 3,6,10 dB, Features • • • • • improved interface matching wideband, DC-2000 MHz, useable to 4 GHz excellent VSWR, 1.1:1 typ. excellent flatness, ±0.1 dB typ. rugged unibody construction DC to 2000 MHz Applications Type-SMA/BNC Type-N/BNC • instrumentation • provides attenuation and connector type change • minimizes hardware Electrical Specifications MODEL NO. CONNECTOR TYPE conn1 SM-BM-3 SM-BM-6 SM-BM-10 SMA-Male SMA-Male SMA-Male conn 2 BNC-Male BNC-Male BNC-Male FREQ. (MHz) fL-fU DC-2000 DC-2000 DC-2000 Nom. 3±0.3 6±0.3 10±0.3 ATTENUATION (dB) Flatness* L M Typ. Max. Typ. Max. VSWR (:1) U 0.15 0.25 1.1 0.15 0.25 1.1 0.10 0.20 1.1 L 1.2 1.2 1.2 1.1 1.1 1.1 M Typ. Max. CASE PRICE $ STYLE U Typ. Max. Qty. (1-24) Typ. Max. Typ. Max. 0.05 0.15 0.05 0.15 0.05 0.10 0.10 0.20 0.10 0.20 0.10 0.15 1.2 1.2 1.3 1.2 1.25 DJ869 1.2 1.25 DJ869 1.2 1.25 DJ869 19.95 19.95 19.95 SF-BM-3 SF-BM-6 SF-BM-10 SMA-Female SMA-Female SMA-Female BNC-Male BNC-Male BNC-Male DC-2000 DC-2000 DC-2000 3±0.3 6±0.3 10±0.3 0.05 0.15 0.05 0.15 0.05 0.15 0.10 0.20 0.10 0.20 0.10 0.15 0.15 0.25 1.1 0.15 0.25 1.1 0.10 0.20 1.1 1.2 1.2 1.2 1.1 1.1 1.1 1.2 1.2 1.3 1.2 1.25 DJ870 1.2 1.25 DJ870 1.2 1.25 DJ870 19.95 19.95 19.95 SM-BF-3 SM-BF-6 SM-BF-10 SMA-Male SMA-Male SMA-Male BNC-Fem BNC-Fem BNC-Fem DC-2000 DC-2000 DC-2000 3±0.3 6±0.3 10±0.3 0.05 0.15 0.05 0.15 0.05 0.15 0.10 0.20 0.10 0.20 0.10 0.15 0.15 0.25 1.1 0.15 0.25 1.1 0.10 0.20 1.1 1.2 1.2 1.2 1.1 1.1 1.1 1.2 1.2 1.3 1.2 1.25 DJ871 1.2 1.25 DJ871 1.2 1.25 DJ871 19.95 19.95 19.95 SF-BF-3 SF-BF-6 SF-BF-10 SMA-Female SMA-Female SMA-Female BNC-Fem BNC-Fem BNC-Fem DC-2000 DC-2000 DC-2000 3±0.3 6±0.3 10±0.3 0.05 0.15 0.05 0.15 0.05 0.10 0.10 0.20 0.10 0.20 0.10 0.15 0.15 0.25 1.1 0.15 0.25 1.1 0.10 0.20 1.1 1.2 1.2 1.2 1.1 1.1 1.1 1.2 1.2 1.3 1.2 1.25 DJ872 1.2 1.25 DJ872 1.2 1.25 DJ872 19.95 19.95 19.95 NM-BM-3 NM-BM-6 NM-BM-10 N-Male N-Male N-Male BNC-Male BNC-Male BNC-Male DC-2000 DC-2000 DC-2000 3±0.3 6±0.3 10±0.3 0.10 0.20 0.05 0.15 0.05 0.15 0.20 0.25 0.15 0.25 0.15 0.25 0.20 0.30 1.1 1.2 0.20 0.25 1.1 1.2 0.20 0.25 1.1 1.2 1.1 1.1 1.1 1.2 1.2 1.3 1.2 1.30 DJ865 1.2 1.25 DJ865 1.2 1.25 DJ865 19.95 19.95 19.95 NF-BM-3 NF-BM-6 NF-BM-10 N-Female N-Female N-Female BNC-Male BNC-Male BNC-Male DC-2000 DC-2000 DC-2000 3±0.3 6±0.3 10±0.3 0.05 0.15 0.05 0.15 0.05 0.15 0.10 0.25 0.10 0.20 0.10 0.25 0.17 0.25 1.1 0.15 0.25 1.1 0.15 0.30 1.1 1.2 1.2 1.2 1.1 1.1 1.1 1.2 1.2 1.3 1.2 1.25 DJ867 1.2 1.25 DJ867 1.2 1.25 DJ867 19.95 19.95 19.95 NM-BF-3 NM-BF-6 NM-BF-10 N-Male N-Male N-Male BNC-Fem BNC-Fem BNC-Fem DC-2000 DC-2000 DC-2000 3±0.3 6±0.3 10±0.3 0.05 0.15 0.05 0.15 0.05 0.15 0.10 0.20 0.10 0.20 0.15 0.25 0.15 0.25 1.1 0.15 0.25 1.1 0.20 0.30 1.1 1.2 1.2 1.2 1.1 1.1 1.1 1.2 1.2 1.2 1.2 1.25 DJ866 1.2 1.25 DJ866 1.2 1.25 DJ866 19.95 19.95 19.95 NF-BF-3 NF-BF-6 NF-BF-10 N-Female N-Female N-Female BNC-Fem BNC-Fem BNC-Fem DC-2000 DC-2000 DC-2000 3±0.3 6±0.3 10±0.3 0.05 0.15 0.05 0.15 0.05 0.15 0.10 0.20 0.10 0.20 0.10 0.15 0.15 0.25 1.1 0.15 0.25 1.1 0.10 0.20 1.1 1.2 1.2 1.2 1.1 1.1 1.1 1.2 1.2 1.3 1.2 1.25 DJ868 1.2 1.25 DJ868 1.2 1.25 DJ868 19.95 19.95 19.95 * Flatness defined as peak to peak attenuation over band divided by 2 L= DC-500 MHz M= DC-1000 MHz U= DC- fU MHz Maximum Ratings Operating Temperature Storage Temperature Input Power -55°C to 100°C -55°C to 100°C 0.5W Max. Mini-Circuits ® REV. A M83075 N/BNC EE-9890 SMA/BNC EE-9890 ADPTENUATOR URJ/TD/CP 020906 Page 1 of 2 INTERNET http://www.minicircuits.com P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 Distribution Centers NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010 ISO 9001 CERTIFIED Adaptenuators Outline Drawing Type-SMA/BNC Type-N/BNC Outline Dimensions ( inch ) mm Case No. DJ865 DJ866 DJ867 DJ868 DJ869 DJ870 DJ871 DJ872 A .812 20.62 .812 20.62 — — — — .312 7.92 — — .312 7.92 — — B .88 22.35 .88 22.35 .73 18.54 .73 18.54 .61 15.49 .61 15.49 .55 13.97 .55 13.97 D 2.25 57.15 2.03 51.56 2.00 50.80 1.79 45.47 1.89 48.01 1.69 42.93 1.68 42.67 1.47 37.34 wt. grams 63.8 57.0 48.2 40.2 25.8 24.0 18.8 16.2 Mini-Circuits ® Page 2 of 2 INTERNET http://www.minicircuits.com P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 Distribution Centers NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010 ISO 9001 CERTIFIED
