SM-SM50

Coaxial Adapter, SMA-M to SMA-M 50Ω DC to 18 GHz Features ! NEW SM-SM50 • flat response • excellent VSWR, 1.10: typ. up to 12.4 GHz and 1.15:1 typ. up to 18 GHz • low cost adapters, available from stock • rugged stainless steel body, gold plated Applications CASE STYLE: DJ951 • interconnection of RF cables and equipment Electrical Specifications TAMB=25°C MODEL NO. CONNECTOR TYPE CONN 1 CONN 2 SMA-MALE SMA-MALE FREQUENCY (GHz) fL-fU DC-18 DC-8 GHz 1.12 VSWR (:1) Max. DC-12.4 GHz 1.30 DC-18 GHz 1.40 PRICE $ Qty. (1-49) 5.95 SM-SM50 Maximum Ratings Operating Temperature Storage Temperature -55°C to 100°C -55°C to 100°C Outline Drawing Outline Dimensions ( inch ) mm A .312 7.92 B D .36 .87 9.14 22.10 E .312 7.92 G .215 5.46 H .15 3.81 wt. grams 4.8 Mini-Circuits ® INTERNET http://www.minicircuits.com P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 REV. A M90500 SM-SM50 ED-10283 YB/CP 040109 Distribution Centers NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010 ISO 9001 CERTIFIED
