C16-004-5810B

MITSUMI USB Series "Mini-AB" Connectors CAM-E43ASF · E43ADF · E43SDF Connectors FEATURES 1. Ultra-small size realized for 5 pins. Volume as compared to conventional Mitsumi product : 1/5 Coupling projection area ratio : 1/4 2. It is the most suitable for connection with PC peripheral equipment with slim PCs, PDAs, mobile phones and so on. 3. Utilizes a sequential function that slides power supply and signal contact connection timing. 4. Couple/decouple reliability ensured for 5,000 times. 5. Weight : 0.6g 6. Supports USB 2.0 (on-the-Go). (DIP with Shield) CAM-E43SDF (DIP type) (SMT type) CAM-E43ASF CAM-E43ADF HOW TO ORDER 1. CAM-E43ASF 2. CAM-E43ADF 3. CAM-E43SDF E43ASF-005-7013A 1 2 3 1 Series No. (E43ASF) 2 No. of contacts (005 : 5pins) 3 Running No. assigned by us E43ADF-005-9024A 1 2 3 1 Series No. (E43ADF) 2 No. of contacts (005 : 5pins) 3 Running No. assigned by us E43SDF-005-8555A 1 2 3 1 Series No. (E43SDF) 2 No. of contacts (005 : 5pins) 3 Running No. assigned by us SPECIFICATIONS ELECTRICAL CHARACTERISTICS Rated Voltage Rated Current Withstanding Voltage Insulation Resistance Contact Resistance MECHANICAL CHARACTERISTICS Life (Matching Cycle) Total Insertion Force Total Withdrawal Force 5,000 times 35N (3.57kgf) max. Beginning 7N (0.71kgf) min. After 5,000 times 3N (0.31kgf) min. AC 5V (rms) 1.0A AC 100V (rms) 1minute 100MΩ min. (AC500V) 50mΩ max. MITSUMI USB Series "Mini-AB" Connectors MATERIAL & FINISH Component Parts Housing Contact Shield Case Material Thermo plastic Copper Alloy Copper Alloy Finish (Gray) Gold plating Tin reflow plating DIMENSIONS CAM-E43ASF (3.2) 3.2±0.05 1.6±0.05 0.5 ±0.05 (6.5) (5.4) (0.8) 2.5 3.7 7.3 (8.5) 2 +0.1 0 (0.7) (2) (4.9) (0.7) 6.9-0 0.1 7.7 ±0.1 +0.2 8.5 -0.1 RECOMMENDED PWB LAYOUT Y 3.95 ±0.1 3.9 ±0.1 9.8 0.4 Y 3.3+0.1 0 6.3-0 0.1 8.1+0.1 0 Unit : mm ±0.05 (5.4) (0.7) (0.7) (2) (4.9) 7.7 ±0.1 +0.2 9 -0.1 +0.2 8.5 -0.1 (0.8) 0.8 +0.1 0 (7.7) +0.1 8.2 0 Y 2 RECOMMENDED PWB LAYOUT 0.4 (0.35) (1.6) (3.2) Y 3.1 ±0.2 1.2 ±0.15 1.2 ±0.15 4.8 ±0.2 2.4 ±0.05 4.8 ±0.05 0.9 CAM-E43ADF 1.2 ±0.05 Unit : mm CAM-E43SDF (3.2) (1.6) (0.35) 3.2±0.05 1.6±0.05 0.5±0.05 1.6 +0.1 0 (6.5) (5.4) (0.8) (8.5) (0.7) (2) (4.9) 0.8 +0.1 0 8.2 +0.1 0 7.7 ±0.1 +0.2 8.5 -0.1 (8.5) RECOMMENDED PWB LAYOUT Y 3.9 ±0.1 Y 1.2 ±0.15 3.1±0.2 4.8 ±0.2 1.6 +0.1 0 Unit : mm
