KK Mini ® – 2.50mm & 2.54mm Modular Interconnection System KK MINI 2.50mm Description Style Vertical, Backwall Right angle, Backwall Circuit Sizes 2 to 20 ckt 2 to 20 ckt 2 to 20 ckt 2 to 20 ckt 2 to 11 ckt Series no. 5045 5046 3022 3094 90578 Material Nylon / Brass Nylon / Brass Nylon / Brass Nylon / Brass Nylon / Brass Packaging Bag Bag Bag Bag Bag Header Vertical Right angle Right angle PCB Connector Top entry Right angle 2 to 20 ckt 7534 Nylon / Phosphor Bronze Tray Housing Crimp housing 2 to 20 ckt 5051 NM Nylon Bag Terminal Basic Anti-fishhooking 2759 4809 Brass Brass Bag or reel Bag or reel KK MINI 2.54mm Description Style Vertical, Backwall Circuit Sizes 2 to 28 ckt 2 to 28 ckt 2 to 28 ckt 2 to 28 ckt Series no. 6410 7395 4030 4094 Material Nylon / Brass Nylon / Brass Nylon / Brass Nylon / Brass Packaging Bag Bag Bag Bag Header Right angle, Backwall Vertical Right angle IDT Vertical 2 to 28 ckt 7720S / 7690 Nylon / Brass Bag KK Mini® – 2.50mm & 2.54mm Modular Interconnection System Top entry PCB Connector Bottom entry Right angle 2 to 25 ckt 4455 Nylon / Brass Tray Housing Crimp housing 2 to 28 ckt 6471 Nylon Bag Terminal Basic Anti-fishhooking 2759 4809 Brass Brass Bag or reel Bag or reel Wire-to-Board and Board-to-Board interconnection system TECHNICAL INFORMATION ■ Housing ■ Contact material ■ Plating ■ Voltage ■ Current rating ■ Mating force ■ Unmating force ■ Temperature operating ■ Temperature non operating Nylon UL 94V-0 & UL 94V-2 Brass or Phosphor Bronze Tin & Gold 250 Volts up to 4.0A 1.95 N maximum per circuit 0.56 N minimum per circuit 0° to +75° C –40° to +105° C KK Mini ® – 2.50mm & 2.54mm Modular Interconnection System Specs vary by product. Please see catalog for details. APPLICATIONS ■ Consumer / Whitegoods Car Stereos, Lighting Panels, Control Panels Kitchen Appliances, Whirlpools, Refrigerators ■ Security / Vending Alarms, Garage Doors, Cameras Lottery Machines, Slot / Pinball Machines, Coin Changers ■ Datacomm / Professional ATM Machines, PC’s, Workstations, Monitors ■ Medical / Office Equipment Heart Monitors, Dental Equipment, Defibilators Projectors, Copiers, Printers, Fax Machines ■ Industrial Elevators, Escalators, Air Conditioning, Central Heating Power Supplies, Industrial Equipment, Lighting Systems KEY FEATURES ■ Available on 2.50 mm and 2.54 mm center spacings ■ Polarisation via insertable keys and pegs ■ Allows connections anywhere on the board ■ Double cantilever style terminal ■ Selective gold plating options ■ End-to-end stacking capabilities ■ Many circuit sizes ■ Locking ramp for improved mated retention with locking headers ■ Accepts KK gas tight crimp terminals ■ IDT option available KK Mini® – 2.50mm & 2.54mm Modular Interconnection System See Molex catalog or www.molex.com for details Americas Headquarters Lisle, Illinois 60532 U.S.A. Tel: 1-800-78MOLEX amerinfo@molex.com Far East North Headquarters Yamato, Kanagawa, Japan Tel: 81-462-65-2324 feninfo@molex.com Far East South Headquarters Jurong, Singapore Tel: 65-6-268-6868 fesinfo@molex.com European Headquarters Munich, Germany Tel: 49-89-413092-0 eurinfo@molex.com Corporate Headquarters 2222 Wellington Ct. Lisle, IL 60532 U.S.A. Tel: 630-969-4550 Visit our Web site at http: //www.molex.com MUN/E033/REV2 Printed in Germany/2K/whp/whp/2003.05 ©Molex Services, 2003
