002-08-2003

This document was generated on 05/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0002082003 Active mlx MLX Crimp Terminal 42023, 14-20 AWG, Reel Tin (Sn) Documents: Drawing (PDF) Product Specification PS-42022-0001 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only General Product Family Series Crimp Quality Equipment Overview Product Name Crimp Terminals 42023 Yes mlx MLX™ EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Male Brass Tin Tin Reel 20 0.50 20 0.50 Crimp or Compression 1.52-3.30mm (.060-.130") 14, 16, 18, 20 N/A Material Info Old Part Number 42023-2A1 Search Parts in this Series 42023Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # FineAdjust™ 0639007500 Applicator for MXL™ Crimp Terminals, 14-20 AWG wire with 2.08 to 2.50mm dia. Insulation FineAdjust™ 0639009800 Applicator for MXL™ Crimp Terminals, 14-20 AWG wire with 2.41 to 2.95mm dia. Insulation FineAdjust™ 0639009900 Applicator for MXL™ Crimp Terminals, Reference - Drawing Numbers Product Specification Sales Drawing PS-42022-0001 SD-42023-**** 14-20 AWG wire with 2.65 to 3.30mm dia. Insulation Tooking Kit for 0639107500 MiniFit Compliant Pin Insertion T2 Terminator 0639109800 Tooling Die for MLX™ Crimp Terminals, 14-20 AWG T2 Terminator 0639109900 Tooling Die for MLX™ Crimp Terminals, 14-20 AWG HAND CRIMP TOOL 0638116800 Extraction Tool 0011010168 This document was generated on 05/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
