This document was generated on 05/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0005060117 Active flat_blade Flat Blade Crimp Terminal, Series 1508, Female, With Tin (Sn) Plated Brass Contact, 14-18 AWG (or 18 AWG Double Crimp), Reel Packaged Documents: Drawing (PDF) RoHS Certificate of Compliance (PDF) Series Crimp Terminals 1508 (2) 18 AWG Yes flat_blade Flat Blade image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Comments Crimp Quality Equipment Overview Product Name Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Female Brass Tin Tin Reel 20 0.50 20 0.50 Crimp or Compression .79mm (.031") max. 14, 16, 18 N/A Material Info Old Part Number 1508-0009 Search Parts in this Series 1508Series Mates With 3.18mm (.125") Male Tab Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Mini-Mac™ 0638941000 Applicator, Singe Wire Applications 16-20 AWG Mini-Mac™ 0638941100 Applicator, Double Crimp Applications 14 AWG Mini-Mac™ 0638941200 Applicator for Reference - Drawing Numbers Sales Drawing SD-1508-0009 Flat Blade Crimp Terminals, 20 AWG Double Crimp Hand Crimper 0011010101 Terminator Die 0011402117 DOUBLES Terminator Die 0011402118 This document was generated on 05/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
