This document was generated on 06/07/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0002062103 Active standard_062 1.57mm (.062") Diameter, Standard .062" Pin and Socket Crimp Terminal, Series 1560, Male, with Tin (Sn) Plated Brass Contact, 18-24 AWG, Bag Documents: Drawing (PDF) RoHS Certificate of Compliance (PDF) Series Crimp Terminals 1560 Yes Yes standard_062 Standard .062" image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Crimp Quality Equipment MolexKits Overview Product Name Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Male Brass Tin Tin Bag 20 0.50 20 0.50 Crimp or Compression 1.52-3.05mm (.060-.120") 18, 20, 22, 24 N/A Material Info Old Part Number 1560-(P901)L Search Parts in this Series 1560Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hand Crimper 0638111000 DISTRIBUTION ONLY Manual Extraction 0011030002 Tool Hand Crimp Tool for 0638191300 Standard .062" Pin and Socket Crimp Terminals, 18-24 AWG Japan Description Product # Hand Insertion Tool 0011020001 Reference - Drawing Numbers Sales Drawing SD-1560-* This document was generated on 06/07/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
