02-09-2101

This document was generated on 05/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0002092101 Active standard_093 2.36mm (.093") Diameter, Standard .093" Pin and Socket Crimp Terminal, Series 1190, Male, with Tin (Sn) Plated Brass Contact, 14-20 AWG, Reel Documents: Drawing (PDF) Product Specification PS-02-09 (PDF) Product Specification PS-43660-9999 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Crimp Quality Equipment Overview Product Name Crimp Terminals 1190 Yes standard_093 Standard .093" Physical Durability (mating cycles max) Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² 25 Male Brass Tin Tin Reel 20 0.50 20 0.50 Crimp or Compression 1.65-4.06mm (.065-.160") 14, 16, 18, 20 N/A Search Parts in this Series 1190Series Use With 1619 Plug or Receptacle Housing, 1545 Plug or Receptacle Housing, 1396 Plug or Receptacle Housing, 1490 Plug or Receptacle Housing, 2629 Plug or Receptacle Crimp Housings, 1261 Plug or Receptacle Housing, 1292 Plug or Receptacle Housing, 1360 Plug or Receptacle Housing, 1375 Plug or Receptacle Housing, 3191 Plug or Receptacle Housing, 2163 Plug or Receptacle Housings Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Mini-Mac™ 0638927100 Applicator Material Info Old Part Number 1190-(P901) Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-1190-001 PS-02-09, PS-43660-9999 SD-1190-* Mini-Mac™ Applicator Insertion Tool Extraction Tool Terminator Die Hand Crimper DISTRIBUTION ONLY 0638927300 0011020003 0011030006 0011402001 0638111000 This document was generated on 05/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
