This document was generated on 05/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0002096110 Active standard_093 2.36mm (.093") Diameter, Standard .093" Pin and Socket Crimp Terminal, Series 1190, Male, with Selective Gold (Au) Plated Brass Contact, 14-20 AWG, Bag Documents: Drawing (PDF) Product Specification PS-02-09 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Crimp Quality Equipment Overview Product Name Crimp Terminals 1190 Yes standard_093 Standard .093" Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Male Brass Gold Gold Bag 50 1.25 10 0.25 Crimp or Compression 1.65-4.06mm (.065-.160") 14, 16, 18, 20 N/A Search Parts in this Series 1190Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hand Crimp Tool 0638191100 Insertion Tool 0011020003 Extraction Tool 0011030006 Hand Crimper 0638111000 DISTRIBUTION ONLY Material Info Old Part Number 1190P591L Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-1190-001 PS-02-09 SD-1190-* This document was generated on 05/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
