08-03-0304

This document was generated on 06/07/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0008030304 Active kk KK® Crimp Terminal 4366, 18-24 AWG, Bag Tin (Sn) Documents: Drawing (PDF) Product Specification PS-09-50 (PDF) RoHS Certificate of Compliance (PDF) General Product Family Series Crimp Quality Equipment Overview Product Name Crimp Terminals 4366 Yes kk KK® Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Female Brass Tin Tin Bag 100 2.50 100 2.50 Crimp or Compression 2.79mm (.110") max. 18, 20, 22, 24 N/A Material Info Old Part Number 4366-P913L Search Parts in this Series 4366Series Use With 4338 KK® Crimp Housing. 11030003 Extraction Tool Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hand Insertion Tool 0011020008 Hand Crimp Tool 0638116600 Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-2759-001 PS-09-50 SD-4366 This document was generated on 06/07/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
