08-50-0004

This document was generated on 03/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0008500004 Active KK® High Pressure Crimp Terminal 7879, 22-30 AWG, Reel Tin (Sn) Documents: Drawing (PDF) Product Specification PS-7879 (PDF) RoHS Certificate of Compliance (PDF) General Product Family Series Crimp Quality Equipment Product Name Crimp Terminals 7879 Yes KK® High Pressure image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Series Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Female Brass Tin Tin Reel 200 5.00 200 5.00 Crimp or Compression 1.57mm (.062") max. 22, 24, 26, 28, 30 N/A Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Material Info Old Part Number 7879-1(P102) Search Parts in this Series 7879Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Extraction Tool 0011030022 Terminator Die 0011402251 Insertion Tool 0638120000 Hand Crimp Tool 0638190800 Mini-Mac™ 0638915100 Applicator Reference - Drawing Numbers Product Specification Sales Drawing PS-7879 SD-7879 This document was generated on 03/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
