08-52-0071

This document was generated on 06/07/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0008520071 Active kk 3.96mm (.156") Pitch KK® Crimp Terminal 2478, 18-24 AWG, Reel, Phosphor Bronze, Tin (Sn) Documents: Drawing (PDF) Product Specification PS-08-50 (PDF) RoHS Certificate of Compliance (PDF) Series General Product Family Series Crimp Quality Equipment Overview Product Name Crimp Terminals 2478 Yes kk KK® image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Female Phosphor Bronze Tin Tin Reel 100 2.50 100 2.50 Crimp or Compression 2.79mm (.110") max. 18, 20, 22, 24 N/A Material Info Old Part Number 2478-3-(P909) Search Parts in this Series 2478Series Use With 2574 , 2139 , 41695 , 3069 , 6422 , 5265 , 5239 Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Extraction Tool 0011030016 Terminator Die 0011402096 Hand Crimper 0638117500 FineAdjust™ 0639007200 Applicator for KK® and Trifurcon™ Crimp Terminal FineAdjust for 0639007300 Mini-Fit Jr.™ Reference - Drawing Numbers Product Specification Sales Drawing PS-08-50 SD-2478 Crimp Terminals Special cut-off tab width for 2478 Series terminals using the 7241 Series IDT housing only. 2478 Series terminals are not rated for USCAR21compliancy. This document was generated on 06/07/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
