08-52-0101

This document was generated on 05/20/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0008520101 Active kk KK® Crimp Terminal 6459, 22-30 AWG, Reel, Phosphor Bronze Tin (Sn) Documents: Drawing (PDF) Product Specification PS-10-07 (PDF) RoHS Certificate of Compliance (PDF) General Product Family Series Crimp Quality Equipment Overview Product Name Crimp Terminals 6459 Yes kk KK® Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Female Phosphor Bronze Tin Tin Reel 100 2.50 100 2.50 Crimp or Compression 1.57mm (.062") max. 22, 24, 26, 28, 30 N/A Material Info Old Part Number 6459-(P909) Search Parts in this Series 6459Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Mini-Mac™ 0638882100 Applicator, Use with Small Wire Insulation Diameter Mini-Mac™ 0638882000 Applicator, Use with Large Wire Insulation Diameter Extraction Tool 0011030022 Terminator Die 0011402265 Insertion Tool 0638120000 Reference - Drawing Numbers Product Specification Sales Drawing PS-10-07 SD-6459 This document was generated on 05/20/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
