08-56-0108

This document was generated on 05/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0008560108 Active kk 3.96mm (.156") Pitch KK® Crimp Terminal 2578, 22-26 AWG, Bag, Brass, 0.51µm (20µ") Selective Gold (Au) Documents: Drawing (PDF) Product Specification PS-08-50 (PDF) RoHS Certificate of Compliance (PDF) Series General Product Family Series Crimp Quality Equipment Overview Product Name Crimp Terminals 2578 Yes kk KK® image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Female Brass Gold Gold Bag 15 0.375 2 0.05 Crimp or Compression 1.65mm (.065") max. 22, 24, 26 N/A Material Info Old Part Number 2578-(550)L Search Parts in this Series 2578Series Use With 2574 , 2139 , 41695 , 3069 , 6422 , 5265 , 5239 Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # HAND CRIMP TOOL 0638117400 Extraction Tool 0011030016 Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-2759-001 PS-08-50 SD-2578 This document was generated on 05/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
