This document was generated on 06/01/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0008560115 Active kk KK® Cat Ear Crimp Terminal 4809, 22-30 AWG, Bag Selective Gold (Au) Documents: Drawing (PDF) Product Specification PS-10-07 (PDF) Product Specification PS-99020-0088 (PDF) RoHS Certificate of Compliance (PDF) Series Crimp Terminals 4809 Yes kk Cat Ear, KK® image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Crimp Quality Equipment Overview Product Name Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Female Brass Gold Gold Bag 15.2 0.38 4.8 0.12 Crimp or Compression 1.57mm (.062") max. 22, 24, 26, 28, 30 N/A Material Info Old Part Number 4809550L Search Parts in this Series 4809Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hand Crimp Tool 0638118200 Reference - Drawing Numbers Product Specification Sales Drawing PS-10-07, PS-99020-0088 SD-4809-* This document was generated on 06/01/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
