08-70-0102

This document was generated on 05/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0008700102 Active spox_bmi 2.50mm (.098") Pitch SPOX™ Wire-to-Wire Male Crimp Terminal, Reel Documents: 3D Model Drawing (PDF) Product Specification PS-5102-003 (PDF) Product Specification PS-5102-005 (PDF) Product Specification PS-5102-006 (PDF) Product Specification PS-51191-003 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Crimp Quality Equipment Overview Product Name Crimp Terminals 5241 Yes spox_bmi SPOX™ Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Male Brass Tin Tin Reel 35 0.88 35 0.88 Crimp or Compression 1.15-1.90mm (.045-.075") 22, 24, 26, 28 N/A Search Parts in this Series 5241Series Mates With 50802 female crimp terminal Use With 5240 Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hand Crimp Tool 0638190800 FineAdjust™ 0639004600 Applicator for SPOX™ Wire-toBoard and Wire-toWire Terminal, 22-28 AWG Material Info Old Part Number 5241T Reference - Drawing Numbers Product Specification Sales Drawing PS-5102-003, PS-5102-005, PS-5102-006, PS-51191-003 SD-5241* T2 Terminator 0639104600 Tooling Die Japan Description Product # Applicator for M211A 0011260050 Bench Press, 22-28 AWG, for 5241 Crimp Terminal Hand Extraction Tool 0011260060 This document was generated on 05/17/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
