Part Number: Status: Overview: Description:
0008701031 Active
spox_bmi SPOX™ Crimp Terminal 5194, 18-24 AWG, Brass, Reel
Documents: Drawing (PDF) Product Specification PS-5096-003 (PDF) Product Specification PS-5195-001 (PDF) Product Specification PS-5195-002 (PDF) Product Specification PS-5195-003 (PDF) Product Specification PS-5195-004 (PDF) Product Specification PS-5195-005 (PDF) Product Specification PS-5195-006 (PDF) Product Specification PS-5195-007 (PDF) Product Specification PS-5195-009 (PDF) Product Specification PS-5195-010 (PDF) Product Specification PS-5195-011 (PDF) Product Specification PS-5196-001 (PDF) Product Specification PS-5196-004 (PDF)
Product Specification PS-5196-005 (PDF) Product Specification PS-5196-006 (PDF) Product Specification PS-5197-001 (PDF) Product Specification PS-5197-003 (PDF) Product Specification PS-5197-004 (PDF) Product Specification PS-5198-001 (PDF) Product Specification PS-5199-001 (PDF) Product Specification PS-5199-002 (PDF) Product Specification PS-5199-003 (PDF) Product Specification PS-5273-003 (PDF) Product Specification PS-5273-004 (PDF) Product Specification PS-5278-001 (PDF) Product Specification PS-5278-002 (PDF) RoHS Certificate of Compliance (PDF)
Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions.
General
Product Family Series Crimp Quality Equipment Overview Product Name Crimp Terminals 5194 Yes spox_bmi SPOX™
Physical
Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Female Brass Tin Tin Reel 35 0.88 35 0.88 Crimp or Compression 1.30-3.20mm (.051-.126") 18, 20, 22, 24 N/A
Search Parts in this Series 5194Series Use With 5195 , 5196 , 5197 , 5198 , 5199 Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # FineAdjust™ 0639005300 Applicator for 3.96mm (.156") Pitch SPOX™ Crimp Terminal, 18-24 AWG T2 Terminator 0639105300 Tooling Die for SPOX™ Crimp
Material Info
Old Part Number 5194T
Reference - Drawing Numbers
Packaging Specification Product Specification SPK-5194-001 PS-5096-003, PS-5195-001, PS-5195-002, PS-5195-003, PS-5195-004, PS-5195-005, PS-5195-006, PS-5195-007, PS-5195-009, PS-5195-010, PS-5195-011, PS-5196-001, PS-5196-004, PS-5196-005, PS-5196-006, PS-5197-001, PS-5197-003, PS-5197-004, PS-5198-001, PS-5199-001, PS-5199-002, PS-5199-003, PS-5273-003, PS-5273-004,
Sales Drawing
PS-5278-001, PS-5278-002, RPS-5096-001, RPS-5195-001, RPS-5196-002, RPS-5196-003, RPS-5196-004, RPS-5197-001, RPS-5198-003, RPS-5199-001, RPS-5281-001, RPS-5289-002 SD-5194-001
Terminal, 18-24 AWG Hand Crimp Tool 0638116500 Japan Description Product # Applicator for M211A 0011260028 Bench Press, 18-28 AWG, for 5225 and 5194 Crimp Terminal Hand Extraction Tool 0011260100
