10-02-1052

厂商：
MOLEX1
封装：
描述：
10-02-1052 - 5.08mm (.200") Pitch KK® PC Board Connector, Bottom Entry Mount Style B, 1.0μm (40μ") T...

数据手册：

下载10-02-1052.pdf

立即购买

详情介绍
数据手册
价格&库存

10-02-1052 数据手册

This document was generated on 05/21/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0010021052 Active kk 5.08mm (.200") Pitch KK® PC Board Connector, Bottom Entry Mount Style B, 1.0µm (40µ") Tin (Sn), 5 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-99020-0087 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Application Overview Product Name PCB Receptacles 3002 Board-to-Board kk KK® Physical Circuits (Loaded) Color - Resin Durability (mating cycles max) Flammability Glow-Wire Compliant Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to PCB Temperature Range - Operating Termination Interface: Style 5 Natural 25 94V-2 No Phosphor Bronze Tin Tin Nylon 1 Bottom Entry 0.160 In 4.10 mm No None 0.062 In 1.60 mm Tray 0.200 In 5.08 mm 40.00 1.000 40.00 1.00 No 0°C to +75°C Through Hole Search Parts in this Series 3002Series Mates With 3003 , 2599 , 3008 Electrical Current - Maximum per Contact Voltage - Maximum 7A 250V Solder Process Data Duration at Max. Process Temperature (seconds) Lead-free Process Capability 5 Wave Capable (TH only) Max. Cycles at Max. Process Temperature Process Temperature max. C 1 260 Material Info Old Part Number 300205B Reference - Drawing Numbers Product Specification Sales Drawing PS-99020-0087 SDAE-3002-NB This document was generated on 05/21/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

10-02-1052

物料型号： - 型号：0010021052 - 状态：Active（活跃）

器件简介： - 描述：5.08mm (0.200") 间距的KK® PCB板连接器，底部进入式B型，1.0µm (40µ") 锡(Sn)镀层，5个电路。

引脚分配： - 电路（已加载）：5个

参数特性： - 耐久性（最大插配次数）：25次 - 阻燃等级：94V-2 - 金属材质：磷青铜 - 镀层材质：锡 - 树脂材质：尼龙 - 排数：1排 - 接口类型：底部进入 - PCB尾长（英寸）：0.160 In - PCB尾长（毫米）：4.10 mm - PCB厚度推荐（英寸）：0.062 In - PCB厚度推荐（毫米）：1.60 mm - 配合界面间距（英寸）：0.200 In - 配合界面间距（毫米）：5.08 mm - 镀层最小厚度（密耳）：40.00 - 镀层最小厚度（微米）：1.000 - 操作温度范围：0°C至+75°C - 接触最大电流：7A - 最大电压：250V

功能详解： - 产品系列：3002 - 应用：板对板 - 产品名称：KKR - 极性：不与PCB极性匹配 - 通孔式接线

应用信息： - 与3003、2599、3008型号相匹配 - 无铅工艺能力

封装信息： - 包装类型：Tray（托盘）
