10-05-1043

This document was generated on 06/07/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0010051043 Active kk 5.08mm (.200") Pitch PC Board Connector, Right Angle Mount, 4 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-2767-012 (PDF) Product Specification PS-2767-013 (PDF) RoHS Certificate of Compliance (PDF) Series Agency Certification CSA UL LR19980 E29179 image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Application Overview Product Name PCB Receptacles 2767 Board-to-Board kk KK® Physical Circuits (Loaded) Flammability Glow-Wire Compliant Material - Metal Material - Plating Mating Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Polarized to PCB Temperature Range - Operating Termination Interface: Style 4 94V-2 No Brass Tin-Lead 1 Right Angle 0.157 In 4.00 mm No Yes 0.062 In 1.60 mm Bag 0.200 In 5.08 mm No -40°C to +105°C Through Hole Search Parts in this Series 2767Series Mates With 5279na Electrical Current - Maximum per Contact Voltage - Maximum 7A 250V Material Info Old Part Number 2767-4AH Reference - Drawing Numbers Product Specification Sales Drawing PS-2767-012, PS-2767-013 SD-2767-NAH This document was generated on 06/07/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
