10-08-1071

This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0010081071 Active kk 5.08mm (.200") Pitch KK® Header, Vertical, Round Pin, 7 Circuits, Tin (Sn) Plating, Pin Length 19.05mm (.750") Documents: 3D Model Drawing (PDF) Product Specification PS-99020-0087 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Application Overview Product Name PCB Headers 3003 Board-to-Board, Wire-to-Board kk KK® Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Pitch - Term. Interface (in) Pitch - Term. Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB No 7 7 Natural 25 No 94V-2 No No None None Brass Tin Tin Nylon 1 Vertical 0.155 In 3.94 mm No None 0.062 In 1.60 mm Bag 0.200 In 5.08 mm 0.200 In 5.08 mm 200 5 200 5 No No Search Parts in this Series 3003Series Mates With KK® Crimp Housing 3001 , 5058. 3002 KK® PC Board Connector Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style No No No 0°C to +50°C Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 7A 250V Solder Process Data Lead-free Process Capability Wave Capable (TH only) Material Info Old Part Number 3003-07A Reference - Drawing Numbers Product Specification Sales Drawing PS-99020-0087 SDAE-3003-N* This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
