10-08-1081

厂商：
MOLEX1
封装：
描述：
10-08-1081 - 5.08mm (.200") Pitch KK® Header, Vertical, Round Pin, 8 Circuits, Tin (Sn) Plating, Pin...

数据手册：

下载10-08-1081.pdf

立即购买

详情介绍
数据手册
价格&库存

10-08-1081 数据手册

This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0010081081 Active kk 5.08mm (.200") Pitch KK® Header, Vertical, Round Pin, 8 Circuits, Tin (Sn) Plating, Pin Length 28.58mm (1.125") Documents: 3D Model Drawing (PDF) Product Specification PS-99020-0087 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Application Overview Product Name PCB Headers 3003 Board-to-Board, Wire-to-Board kk KK® Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Pitch - Term. Interface (in) Pitch - Term. Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB No 8 8 Natural 25 No 94V-2 No No None None Brass Tin Tin Nylon 1 Vertical 0.155 In 3.94 mm No None 0.062 In 1.60 mm Bag 0.200 In 5.08 mm 0.200 In 5.08 mm 200 5 200 5 No No Search Parts in this Series 3003Series Mates With KK® Crimp Housing 3001 , 5058. 3002 KK® PC Board Connector Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style No No No 0°C to +50°C Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 7A 250V Solder Process Data Lead-free Process Capability Wave Capable (TH only) Material Info Old Part Number 300308A Reference - Drawing Numbers Product Specification Sales Drawing PS-99020-0087 SDAE-3003-N* This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

10-08-1081

1. 物料型号 - 型号：0010081081 - 状态：Active（活跃）

2. 器件简介 - 描述：5.08mm (.200") Pitch KK® Header, Vertical, Round Pin, 8 Circuits, Tin (Sn) Plating, Pin - 长度：28.58mm(1.125") - 文档：3D Model Drawing (PDF), Product Specification PS-99020-( RoHS Certificate of Compliance ( 等

3. 引脚分配 - 引脚数量：8 Circuits (Loaded) - 最大引脚数量：8 Circuits (maximum)

4. 参数特性 - 耐久性（最大插拔次数）：25次 - 阻燃等级：94V-2 - 引脚材料：Brass - 镀层：Tin over Brass - 镀层厚度：min. 200u" (5um) on Mating and Termination

5. 功能详解 - 应用：Board-to-Board, Wire-to-Board - 系列：3003 - 产品名称：KKR - PCB厚度推荐：0.062 In (1.60 mm)

6. 应用信息 - 工作温度范围：0℃ to +50℃ - 最大电流每接触点：7A - 最大电压：250V - 焊接过程数据：Lead-free Process Capability, Wave Capable (TH only)

7. 封装信息 - 封装类型：Bag - 接口间距（Mating Interface）：5.08 mm (0.200 In) - 引脚方向：Vertical - PCB尾长：0.155 In (3.94 mm)
