10-08-1102

厂商：
MOLEX1
封装：
描述：
10-08-1102 - 5.08mm (.200") Pitch KK® Header, Vertical, Round Pin, 10 Circuits, Tin (Sn) Plating, Pi...

数据手册：

下载10-08-1102.pdf

立即购买

详情介绍
数据手册
价格&库存

10-08-1102 数据手册

This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0010081102 Active kk 5.08mm (.200") Pitch KK® Header, Vertical, Round Pin, 10 Circuits, Tin (Sn) Plating, Pin Length 23.80mm (.937") Documents: 3D Model Drawing (PDF) Product Specification PS-99020-0087 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Application Overview Product Name PCB Headers 3003 Board-to-Board, Wire-to-Board kk KK® Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Pitch - Term. Interface (in) Pitch - Term. Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB Shrouded No 10 10 Natural 25 No 94V-2 No No None None Brass Tin Tin Nylon 1 Vertical 0.155 In 3.94 mm No None 0.062 In Bag 0.200 In 5.08 mm 0.200 In 5.08 mm 200 5 200 5 No No No Search Parts in this Series 3003Series Mates With KK® Crimp Housing 3001 , 5058. 3002 KK® PC Board Connector Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style No No 0°C to +50°C Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 7A 250V Material Info Old Part Number 300310B Reference - Drawing Numbers Product Specification Sales Drawing PS-99020-0087 SDAE-3003-N* This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

10-08-1102

1. 物料型号： - 型号：0010081102 - 状态：Active（活跃）

2. 器件简介： - 描述：5.08mm（0.200英寸）间距KK®公头，垂直，圆针，10路，锡（Sn）镀层，符合欧盟RoHS、中国RoHS、ELV和RoHS指令，REACH SVHC未审核，卤素状态未审核。

3. 引脚分配： - 引脚长度：23.80mm（0.937英寸） - 电路数（已装填）：10 - 电路数（最大）：10

4. 参数特性： - 耐用性（最大插拔次数）：25次 - 阻燃等级：94V-2 - 金属材质：黄铜 - 镀层：锡 - 排数：1 - 导向：无 - 锁紧：无 - 极性：无 - 推荐PCB厚度：0.062英寸

5. 功能详解： - 产品系列：3003 - 应用：板对板、线对板 - 物理特性：无断路 - 颜色：自然色

6. 应用信息： - 与KK®压接式外壳3001、5058、3002兼容 - 堆叠表面贴装兼容（SMC） - 工作温度范围：0°C至+50°C - 最大每接触点电流：7A - 最大电压：250V

7. 封装信息： - 封装类型：袋装 - 接口间距（接口）：5.08mm（0.200英寸） - 接口间距（终止）：5.08mm（0.200英寸） - 镀层最小厚度：镀锡（2.5um/0.000100英寸）
